MIRAEPO NC TOTAL TOOLING SYSTEM

▣ Diamond Grinding Stone / Diamond Dresser

∅D ∅d
H

L

Diamond Grinding Stone Short Diamond Grinding Stone
(다이아몬드 추지석) [I-CBN] (숏 다이아몬드 추지석)

규격 D d L H 가격 규격 Dd L H 가격
I-CBN1.0 ∅1.3 ∅1.0 71 10 9,000 60 10 9,500
I-CBN1.5 ∅1.8 ∅1.5 71 9,000 I-CBN6.0-60S ∅6.3 ∅6.0 10,000
I-CBN2.0 ∅2.3 ∅2.0 76 15 9,000 70 15 10,200
I-CBN3.0 ∅3.3 ∅3.0 82 22 9,000 I-CBN7.0-60S ∅7.3 ∅7.0 80 22 10,800
I-CBN4.0 ∅4.3 ∅4.0 86 9,200 12,300
I-CBN5.0 ∅5.3 ∅5.0 91 9,400 I-CBN8.0-60S ∅8.3 ∅8.0 13,000
I-CBN6.0 ∅6.3 ∅6.0 91 9,500 13,700
I-CBN7.0 ∅7.3 ∅7.0 91 10,000 I-CBN10.0-60S ∅10.3 ∅10.0 14,400
I-CBN8.0 ∅8.3 ∅8.0 100 10,200 15,100
I-CBN9.0 ∅9.3 ∅9.0 110 10,600 I-CBN11.0-70S ∅11.3 ∅11.0 15,800
I-CBN10.0 ∅10.3 ∅10.0 121 10,800
I-CBN11.0 ∅11.3 ∅11.0 121 12,300 I-CBN12.0-70S ∅12.3 ∅12.0
I-CBN12.0 ∅12.3 ∅12.0 131 13,000
I-CBN13.0 ∅13.3 ∅13.0 131 13,700 I-CBN13.0-70S ∅13.3 ∅13.0
I-CBN14.0 ∅14.3 ∅14.0 140 14,400
I-CBN15.0 ∅15.3 ∅15.0 150 15,100 I-CBN14.0-80S ∅14.3 ∅14.0
I-CBN16.0 ∅16.3 ∅16.0 150 15,800
I-CBN15.0-80S ∅15.3 ∅15.0

I-CBN16.0-80S ∅16.3 ∅16.0

- 특 징-

∙동심도가 정확하여 절삭이 잘됨.
∙흔들림이 거의 없어 절삭력이 강함.
∙다른 추지석에 비해 마모가 적음.

Diamond Grinding Stone Diamond Dresser (다이아몬드 드레샤)
(다이아몬드 추지석) [I-DIA]

규격 D dL H 가격 Fig 1
I-DIA1.0 ∅1.3 ∅1.0 71 10 9,000 ∅D
I-DIA2.0 ∅2.3 ∅2.0 76 9,000
I-DIA3.0 ∅3.3 ∅3.0 82 9,000 L
I-DIA4.0 ∅4.3 ∅4.0 86 9,200
I-DIA5.0 ∅5.3 ∅5.0 91 9,400 Fig 2
I-DIA6.0 ∅6.3 ∅6.0 91 9,500 ∅D
I-DIA7.0 ∅7.3 ∅7.0 91 10,000
I-DIA8.0 ∅8.3 ∅8.0 100 10,200 L
I-DIA9.0 ∅9.3 ∅9.0 110 10,600
I-DIA10.0 ∅10.3 ∅10.0 121 10,800 규격 Fig D L Diamond 가 격

DW12-3/4 1 48 3/4 16,500

DW12-1.5 12 1.5 30,200

DD12-3/4 2 90 3/4 12,100

DD12-1/2 1/2 17,300
