MIRAEPO NC TOTAL TOOLING SYSTEM

▣ DIN69871 40(SK40) / DIN69871 50(SK50)

Shell Endmill Arbor (쉘 엔드밀 아버)

H1 L1

G

∅D ∅D1

규격 D1 L1 H1 DG 가격
38 96,500
DIN69871 40-SEM16-35 16 35 17 47 96,500
58 M16 96,500
DIN69871 40-SEM22-35 22 35 19 66 101,200
82 110,300
DIN69871 40-SEM27-60 27 60 21 38 142,800
47 142,800
DIN69871 40-SEM32-60 32 60 24 50 240,600
58 M24 142,800
DIN69871 40-SEM40-60 40 60 27 66 142,800
82 162,400
DIN69871 50-SEM16-35 16 35 17 95 208,700

DIN69871 50-SEM22-35 22 35 19

DIN69871 50-SEM22-200 22 200 19

DIN69871 50-SEM27-35 27 35 21

DIN69871 50-SEM32-35 32 35 24

DIN69871 50-SEM40-50 40 50 27

DIN69871 50-SEM50-60 50 60 30

Face Mill Arbor (페이스 밀 아버)

H1 L1

P·C·D ∅ ∅D1
D

M1

규격 D1 L1 H1 D M1 P·C·D Mounting 가격
Screw 174,500
209,100
DIN69871 40 FM40 40 60 M12x1.75 271,700
30 88 M20 66.7 S.H.C.S

DIN69871 50 FM50 50 70

DIN69871 50 FM60 60 70 40 128 - 101.6 M16x2
S.H.C.S
