Page 159 - SSK

Hydraulic
Chuck

SIDE LOCK ARBOR SLB Shrink Fit
Holder

Milling
Chuck

SK Slim
Chuck

ER Collet
Chuck

JIS B6339-BT JIS B6339 Taper G Value RPM Coolant N&COHDtroilhlledreCrThsouoclk
- BT Accuracy - - System

AT3 -

TAPER No. MODEL No. d1 D1 L H1 H2 M W N 중량(Kg) Unit : mm Morse TaperArbor
40 BT40-SLB26-105 1.30 재고
BT40-SLB35-135 2.20
50 BT40-SLB35T-135 26 50 105 40 85 M10 5 28.2 2.20
BT50-SLB26-105 4.40
BT50-SLB35-135 35 60 135 55 105 M10 6 37.6 4.70
BT50-SLB35T-135 4.70
BT50-SLB48-165 35 60 135 55 105 M10 7 38.2 6.50

26 50 105 40 85 M10 5 28.2 Synchro Tapping Chuck

35 60 135 55 106 M10 6 37.6

35 60 135 55 106 M10 7 38.2

48 80 165 65 129 M10 8 51.0

▶ Side Lock Arbor의 표준설계는 Straight Shank 공구를 기준으로 설계 Tapping ER
Chuck
PARTS (ForENDMILLHOLDER) & SIDE LOCK HOLDER SCREW

M Tapping
Chuck

L Side Lock Arbor
& End Mill Holder
M Unit : mm
EMH & SLA Dia.
SLA EMH L Face Mill
6 SLA EMH Arbor
8 M5x0.8 M6x1.0
10 8 10.5
12 M6x1.0 M8x1.25 10 10.5
14 12 12.5
16 M8x1.25 M10x1.5 14 16.5
18 14 15
20 M10x1.5 M12x1.75 12 16.5
25 - 16.5
32 M10x1.5 M12x1.75 16 16.5 Shell Mill
40 14 20.5 Arbor
42 M12x1.75 M14x2.0 16 20.5
50 16 25.5
50.8 - M14x2.0 16 -
- 25.5
M12x1.75 M16x2.0 25 -

M14x2.0 M18x2.0

M16x2.0 M20x2.0

M16x2.0 M20x2.0 Boring
System
M16x2.0 -

- M24x2.0

M20x2.5 -

TOOL CO., LTD. www.ssktool.co.kr 159 Accessory
