FINE BORING BAR (SMALLBORE) BAH Shrink Fit
Holder
L
FIG. 1 L FIG. 2 L1 Milling
L1 Chuck
L2

L2

Ø31 SK Slim
D Chuck

D

ER Collet
Chuck

JIS B6339-BT JIS B6339 Taper G Value RPM Coolant N&COHDtroilhlledreCrThsouoclk
- BT Accuracy - - System

AT3 AD
Unit : mm
TAPER No. MODEL No. BORE RANGE D L L1 L2 FIG. 중량(Kg) 재고 Morse TaperArbor
30 (FRONT)
40 BT30-BAH1-105 20~26 19 104.5 72 73 1 ● Synchro Tapping Chuck
BT30-BAH2-75 25~33 24 73 37.5 48 2 ●
50 BT30-BAH2-120 25~33 24 118 82.5 93 2 ● Tapping ER
BT30-BAH3-80 32~42 31 79 39 53 2 ● Chuck
BT30-BAH3-120 32~42 31 119 79 93 2 ●
BT30-BAH4-85 41~54 39 85 38 58 2 ● Tapping
BT30-BAH4-120 41~54 39 120 73 93 2 ● Chuck
BT30-BAH5-120 53~70 50 120 63 93 2 ●
BT40-BAH1-105 20~26 19 72 73 2 ● Side Lock Arbor
BT40-BAH2-80 25~33 24 104.5 42.5 48 2 ● & End Mill Holder
BT40-BAH2-120 25~33 24 78 82.5 88 2
BT40-BAH3-85 32~42 31 118 44 53 2 187 Face Mill
BT40-BAH3-135 32~42 31 84 94 103 2 Arbor
BT40-BAH4-90 41~54 39 134 43 58 2
BT40-BAH4-135 41~54 39 90 88 103 2 Shell Mill
BT40-BAH5-105 53~70 50 135 48 73 2 Arbor
BT40-BAH5-135 53~70 50 105 79 103 2
BT40-BAH6-135 68~100 64 135 64 103 2 Boring
BT50-BAH1-135 20~26 19 135 102 73 1 System
BT50-BAH2-90 25~33 24 52.5 47 2
BT50-BAH2-150 25~33 24 134.5 112.5 107 2
BT50-BAH3-95 32~42 31 88 54 52 2
BT50-BAH3-165 32~42 31 148 124 122 2
BT50-BAH4-105 41~54 39 94 58 62 2
BT50-BAH4-165 41~54 39 164 118 122 2
BT50-BAH4-225 41~54 39 105 178 182 2
BT50-BAH5-120 53~70 50 165 63 77 2
BT50-BAH5-165 53~70 50 225 108 122 2
BT50-BAH5-240 53~70 50 120 183 197 2
BT50-BAH5-285 53~70 50 165 228 242 2
BT50-BAH6-165 68~100 64 240 94 122 2
BT50-BAH6-240 68~100 64 285 169 197 2
BT50-BAH6-300 68~100 64 165 229 257 2
BT50-BAH7-180 100~153 90 240 93 142 2
BT50-BAH7-330 100~153 90 300 243 292 2
180
330
