HYDRAULIC CHUCK HC Shrink Fit
Holder

Milling
Chuck

SK Slim
Chuck

ER Collet
Chuck

CBT Taper G Value RPM Run-Out Coolant N&COHDtroilhlledreCrThsouoclk
Accuracy (at 3D) System

CBT (BT 2면 구속형) AT3 2.5 25,000 ≤3Um AD

Unit : mm Morse Taper

TAPER No. MODEL No. d1 D1 D2 L L1 L2 G 중량(Kg) 재고 Arbor
50 CBT50-HC6-90 6 26 44.5 90 34
CBT50-HC6-120 6 26 44.5 120 34 27 M5×0.8 3.75
CBT50-HC6-150 6 26 44.5 150 34
CBT50-HC8-90 8 28 44.5 90 34 27 M5×0.8 4.10
CBT50-HC8-120 8 28 44.5 120 34
CBT50-HC8-150 8 28 44.5 150 34 27 M5×0.8 4.70
CBT50-HC10-90 10 30 44.5 90 34
CBT50-HC10-120 10 30 44.5 120 34 27 M6×1.0 3.75 Synchro Tapping Chuck
CBT50-HC10-150 10 30 44.5 150 34
CBT50-HC12-90 12 32 44.5 90 34 27 M6×1.0 4.10
CBT50-HC12-120 12 32 44.5 120 34
CBT50-HC12-150 12 32 44.5 150 34 27 M6×1.0 4.10
CBT50-HC14-90 14 34 44.5 90 34
CBT50-HC14-120 14 34 44.5 120 34 32 M8×1.0 3.90
CBT50-HC14-150 14 34 44.5 150 34
CBT50-HC16-90 16 38 44.5 90 34 32 M8×1.0 4.30 Tapping ER
CBT50-HC16-120 16 38 44.5 120 34 Chuck
CBT50-HC16-150 16 38 44.5 150 34 32 M8×1.0 4.90
CBT50-HC18-90 18 40 44.5 90 34
CBT50-HC18-120 18 40 44.5 120 34 37 M10×1.0 3.90 ●
CBT50-HC18-150 18 40 44.5 150 34
CBT50-HC20-90 20 42 44.5 90 34 37 M10×1.0 4.30
CBT50-HC20-120 20 42 44.5 120 34
CBT50-HC20-150 20 42 44.5 150 34 37 M10×1.0 4.90
CBT50-HC25-105 25 57 63 105 52
CBT50-HC25-150 25 57 63 150 97 37 M10×1.0 3.90 Tapping
CBT50-HC32-115 32 64 75 115 62 Chuck
CBT50-HC32-150 32 64 75 150 97 37 M10×1.0 4.30

37 M10×1.0 4.90

42 M12×1.0 4.00

42 M12×1.0 4.40 Side Lock Arbor
& End Mill Holder
42 M12×1.0 5.00

42 M12×1.0 4.00

42 M12×1.0 4.40

42 M12×1.0 5.00

42 M16×1.0 4.00 ● Face Mill
Arbor
42 M16×1.0 4.40

42 M16×1.0 5.00

48 M16×1.0 4.40

48 M16×1.0 5.60

55 M16×1.0 4.70 ● Shell Mill
Arbor
55 M16×1.0 6.00

▶ CAT(ANSI B5.50) Taper 및 Inch Type 제품 공급 가능
