   Shrink Fit                   DIN 228 (MORSE TAPER) TANGTYPE(MTA)
Holder

   Milling                                                                                                                              R
Chuck
                                                                Ø d2
                                                                           Ø D1
                                                                                             ØD
                                                                                                                                              B

                                                                                                                                                    Ø d1

   SK Slim                                                      CA                                                    E
Chuck                                                                                             L1

                                                                                                  L2

   ER Collet                                                                                                                                              Unit : mm
Chuck

                                TAPER  Taper Taper Angle(α) ØD  A ØD1 Ød1 L1             L2 Ød2                                     B      C   E          R

N&COHDtorhilldel reCTrhsouoclk  MT0 1/19.212  1°29′27″  9.045 3 9.045 6.104 56.5 59.5 6.0 3.9 6.5 10.5 4

                                MT1 1/20.047  1°25′43″ 12.065 3.5 12.065 8.972 62.0 65.5 8.7 5.2 8.5 13.5 5

                                MT2 1/20.020  1°25′50″  17.780 5 17.780 14.034 75.0 80.0 13.5 6.3                                          10  16         6

                                MT3 1/19.922  1°26′16″  23.825 5 23.825 19.107 94.0 99.0 18.5 7.9                                          13  20         7

                                MT4 1/19.254  1°29′15″  31.267 6.5 31.267 25.164 117.5 124.0 24.5 11.9                                     16  24         8

ArborMorse Taper                MT5 1/19.002  1°30′26″  44.399 6.5 44.399 36.531 149.5 156.0 35.7 15.9                                     19  29         10

                                MT6 1/19.180  1°29′36″  63.348 8 63.348 52.399 210.0 218.0 51.0 19.0                                       27  40         13

                                MT7 1/19.231  1°29′22″  83.058 10 83.058 68.186 286.0 296.0 66.8 28.6                                      35  54         19

Tapping ChuckSynchro            DIN 228 (MORSE TAPER) SCREWTYPE(MTB)

   Tapping ER                                                                 K
Chuck                                                                                       R

   Tapping                                    Ø D1
Chuck                                                                ØD
                                                                                                                         Ø d1

                                                                                                                                Ød

                                                                MT No.

   Side Lock Arbor                                                      Ø d2          T
& End Mill Holder
                                                        A L1

                                                                L2

   Face Mill                                                                                                                                              Unit : mm
Arbor
                                TAPER  Taper Taper Angle(α) ØD  A ØD1 d       L1 L2 Ød1 d2                                                 K   T          R

                                MT0 1/19.212  1°29′27″  9.045 3 9.201 6.442 50 53 6.4                                               -      -   4 0.2

                                MT1 1/20.047  1°25′43″  12.065 3.5 12.230 9.396 53.5     57       9.4                               M6     16  5 0.2

   Shell Mill                   MT2 1/20.020  1°25′50″  17.780 5 18.030 14.583 64        69 14.6 M10 24                                        5 0.2
Arbor
                                MT3 1/19.922  1°26′16″  23.825 5 24.076 19.759 81        86 19.8 M12 28                                        7          0.6

                                MT4 1/19.254  1°29′15″  31.267 6.5 31.605 25.943 102.5 109 25.9 M16                                        32  9          1

                                MT5 1/19.002  1°30′26″  44.399 6.5 44.741 37.584 129.5 136 37.6 M20                                        40  9          2.5

                                MT6 1/19.180  1°29′36″  63.348 8 63.765 53.859 182       190 53.9 M24                                      50  12         4

   Boring                       MT7 1/19.231  1°29′22″  83.058 10 83.578 70.058 250 260 70.0 M33 80 18.5                                                  5
System
