알루미늄 가공용 엔드밀 알루웨이브 2

3날 알루미늄 전용 표준 날부 타입, 코너 래디우스 엔드밀 > Metric & Inch

3 FLUTE, STUB LENGTH, CORNER RADIUS END MILLS
- for Aluminum
R
L1 - 알루미늄, 비철금속, 흑연, 플라스틱에 높은 효율을 보이는 구조
L2 - 비코팅, DLC 코팅 모두 사용 가능
D
D2

WAR313A ........series MG 45 비코팅

FINE GRAIN 0.015

HELIX D.L.C.

EDP. No. Dimension (mm)

비코팅 D.L.C.코팅 D R C.L OAL SH.Dia
1/8 1/8
WAR313A008010 WAR513A008010 3/16 .010 3/8 1-1/2 3/16
3/16 3/16
WAR313A012010 WAR513A012010 1/4 .010 9/16 2 1/4
1/4 1/4
WAR313A012020 WAR513A012020 1/4 3/16 9/16 2 1/4
1/4 1/4
WAR313A016010 WAR513A016010 5/16 .010 5/8 2-1/2 5/16
5/16 5/16
WAR313A016020 WAR513A016020 3/8 .020 5/8 2-1/2 3/8
3/8 3/8
WAR313A016030 WAR513A016030 3/8 .030 5/8 2-1/2 3/8
7/16 7/16
WAR313A016060 WAR513A016060 1/2 .060 5/8 2-1/2 1/2
1/2 1/2
WAR313A020020 WAR513A020020 1/2 .020 13/16 2-1/2 1/2
5/8 5/8
WAR313A020030 WAR513A020030 5/8 .030 13/16 2-1/2 5/8
5/8 5/8
WAR313A024020 WAR513A024020 3/4 .020 1 2-1/2 3/4
3/4 3/4
WAR313A024030 WAR513A024030 3/4 .030 1 2-1/2 3/4
1 1
WAR313A024060 WAR513A024060 1 .060 1 2-1/2 1 알루미늄 가공용 엔드밀 - 알루웨이브 시리즈
1 1
WAR313A028020 WAR513A028020 .020 1-1/4 2-3/4

WAR313A032020 WAR513A032020 .020 1-1/4 3

WAR313A032030 WAR513A032030 .030 1-1/4 3

WAR313A032060 WAR513A032060 .060 1-1/4 3

WAR313A040030 WAR513A040030 .030 1-5/8 3-1/2

WAR313A040060 WAR513A040060 .060 1-5/8 3-1/2

WAR313A040090 WAR513A040090 .090 1-5/8 3-1/2

WAR313A048060 WAR513A048060 .060 1-5/8 4

WAR313A048090 WAR513A048090 .090 1-5/8 4

WAR313A048120 WAR513A048120 .120 1-5/8 4

WAR313A064060 WAR513A064060 .060 2 5

WAR313A064090 WAR513A064090 .090 2 5

WAR313A064120 WAR513A064120 .120 2 5

■적용 피삭재 ■허용공차

탄소강 합금강 프리하든강 열처리강 동 흑연 주철 알루미늄 스테인리스강 인선부 (Inch) 자루부
(S45C, S55C...) (SCM, SK...) (NAK...) ~HRc55 SKD61 ~HRc55 SKD11 FCD400. 500~
HB225~325 ○ ◎
~ HB225 HRc30~50
○ ○:적합 ◎:매우적합
0 ~ .0008 h6

※상기 제원은 제품의 품질향상을 위하여 예고없이 변경될 수 있습니다.
