CUTTER SERIES5
RELIEF CUTTER

▶ 릴리프-커터 / Relief Cutter

- STRIGHT SHANK TYPE INSERT TYPE → WIDIN, WALTER, TAEGU-TEC

Part No. 치수(Dimensions)mm NO.OF NO.OF
D d L L1 I INSERT INSERT
RELIEF-D15x10x100L 15 12 100 10 52
RELIFE-D19x10x100L 19 16 100 10 52 2 SPMG ST2204-55 TX-06
RELIFE-D33x25x230L 33 32 230 25 100 TX-20
RELIFE-D33x45x230L 33 32 230 45 100 2 060204 M2.2
RELIFE-D33x45x300L 33 32 300 45 100
RELIFE-D34x25x230L 34 32 230 25 100 2
RELIFE-D34x35x230L 34 32 230 35 100
RELIFE-D34x45x230L 34 32 230 45 100 4
RELIFE-D34x45x300L 34 32 300 45 100
RELIFE-D35x25x230L 35 32 230 25 100 4
RELIFE-D35x45x230L 35 32 230 45 100
RELIFE-D35x45x300L 35 32 300 45 100 2 1 2
RELIFE-D54x45x265L 54 42 265 45 220 3
ZPMT-1504WM 4 SPMT ST511-43
APMT1504 WT 4
120408 M5

2

4

4

42 10

▶ U-홈커터 / U-Home Cutter

커터 시리즈 - STRIGHT SHANK TYPE INSERT TYPE → WIDIN, WALTER, TAEGU-TEC

Part No. 치수(Dimensions)mm NO.OF NO.OF
U-HOME-D32x42x200L INSERT INSERT
D d L L1 I
32 42 200 75 90 7

U-HOME-D34x42x200L 34 42 200 75 90

U-HOME-D35x42x200L 35 42 200 75 90 SPMT ST511-43
120408 M5
U-HOME-D39x42x200L 39 42 200 75 90 2 1 ZPMT-1504WM 8 TX-20

U-HOME-D40x42x200L 40 42 200 75 90

U-HOME-D44x42x200L 44 42 200 75 90

U-HOME-D45x42x200L 45 42 200 75 90
