COOLANT 절삭 데이터 (COOLANT CUTTING DATA)
COOLANT 절삭데이타 (COOLANT CUTTING DATA) DRILL INSERTS (METRIC)-COOLANT RECOMMENDATIONS
MATERIAL FPLROEWSoSrRUARTEE ø9.5~ ø13~ ø18~ HSS CARBIDE
피삭재 ø12.5 ø17.5 ø24 ø25~ ø36~ ø48~ ø76~ ø9.5~ ø13~ ø18~ ø25~ ø36~
ø35 ø47 ø65 ø102 ø12.5 ø17.5 ø24 ø35 ø47
Free Machining Steel Bar 12~13 7~8 7~10 6~8 5~7 4 5~6 17~20 17 15 15 20
연강 LPM 9.5~9.8 10.6~11.4 16.7~19.7 26.5~30.3 45.4~53.0 114~125 144~167 12.2 16.3 25.2 41.5 71.9
Bar 11~12 5~6 5~7 4~6 4~5 2~3 3~5 18 11 11 12 9
1118,1215,12L14,etc LPM 9.1~9.5 9.1~9.8 14.0~15.9 22.7~26.5 41.6~45.4 98~114 125~144 11.4 13.3 20.6 36.5 62
Bar 11 5~6 5~6 4~5 3~5 2~3 3~5 17 10 10 10 8
Low Cabon Steel LPM 8.7~9.1 8.7~9.8 13.6~15.5 18.9~22.7 37.9~45.4 98~114 125~144 11.3 12.5 20 33.8 57
저탄소강 Bar 11 5~6 5~6 3~4 3 2 3 16 9 8 7 5
LPM 8.7~9.1 9.7~9.8 13.2~14.8 18.9~22.7 34.1~37.9 87~98 114~125 10.8 12 17.5 27.8 47.1
1010,1020,1025,
1522,1144,etc
Medium Carbon Steel
중탄소강
1030,1040,1050,1527
1140,1151,ect
Structural Steel
구조용강
A36,A285,A516,ect
Alloy Steel Bar 11 5 5~6 3~5 3~4 2 3 17 9 10 8 7
합금강 LPM 8.7~9.1 8.3~9.1 13.2~14.8 18.9~22.7 31.9~41.6 98~106 114~125 11.1 12.3 19.3 30 55.8
4140,5140,8640,etc
Tool Steel Bar 10~11 4 3 2 2 2 2 15 5 5 3 3
공구강
H-13,H-21,A-4,O-2,S-3,etc LPM 8.7~9.1 7.9~8.3 11.0~11.7 15.1~18.9 26.5~30.3 79~87 87~98 10.4 9.1 13.6 19 36.5
High Temp.Alloy Bar 10~11 4~5 3~4 2 2 2 3 17 11 12 11 9
내열 합금강 LPM 125 11.1 13.5 21.9 35.4 62
8.7~9.1 8.3~8.7 11.7~12.1 15.1~18.9 26.5~30.3 87~98
Hastelloy B,Inconel 600, etc
High Strengh Alloy Bar 10~11 4 3 2 2 1~2 2 15 5 4 3 3
고경도 합금강 LPM 8.7~9.1 7.9~8.3 11.0~11.7 15.1~18.9 26.5~30.3 79~87 87~98 10.4 9.1 12.6 18.8 33.6
4340,4330V,300M, etc
Aluminium Bar 14.5 12.4 15.8 11 8.6 3.5 5.5 24.1 22 21.7 19.6 13.8
알루미늄 LPM 10 14 23 34 61 125 159 13.4 18.8 29 47.2 77
2014,6061,7075, etc
Stainledd Steet 400 Series Bar 11.8 5.9 5.2 3.8 3.5 2 3.1 22.7 16.5 17.9 17.2 13.1
스테인레스강 LPM 9.5 9.8 14 23 38 98 117 13 16.3 26.3 44.2 75
416,420,etc
Stainledd Steet 300 Series Bar 11.8 5.9 5.2 3.8 3.5 2 3.1 22.7 16.5 17.9 17.2 13.1
스테인레스강 LPM 9.5 9.8 14 23 38 98 117 13 16.3 26.3 44.2 75
304,316,17-4PH,etc
HOLDER EXTENDED LONG XL 3XL
Pressure & Flow 1.3 1.5 2 3
48 Coolant Recommendation Example :
If the recommended pressure and flow is 10bar and 25 LPM for a standard
length holder, the adjusted pressure and flow would be 30bar and 75LPM
respectively for the 3XL holder.
ex) 10×3=30bar 25×3=66LPM
