HSS Dovetail Cutters HSS Cutters

60°T-Angle, M2 하이스 티앵글 컷터
60°, SKH51

HSS

Item no. D A No. d L
of Flute
제품코드 외경 날높이 샹크 전장
날수
50
TA01H1-010 10.0 4.5 8 10 52
55
TA01H1-012 12.0 5.5 8 12 55
58
TA01H1-013 13.0 5.5 8 12 58
60
TA01H1-014 14.0 6.0 8 12 65
67
TA01H1-015 15.0 6.8 8 12 70
70
TA01H1-016 16.0 7.2 8 12 73
75
TA01H1-018 18.0 8.0 8 12 75
80
TA01H1-020 20.0 8.0 8 12 83
85
TA01H1-022 22.0 9.0 10 12 90
93
TA01H1-024 24.0 10.0 10 12 110
120
TA01H1-025 25.0 11.5 10 12 130

TA01H1-028 28.0 12.0 10 16

TA01H1-030 30.0 12.5 10 16

TA01H1-032 32.0 14.0 12 16

TA01H1-035 35.0 15.2 12 16

TA01H1-038 38.0 16.0 14 20

TA01H1-040 40.0 17.0 14 20

TA01H1-045 45.0 22.0 14 20

TA01H1-050 50.0 24.0 16 25 Tolerance (허용공차)

TA01H1-060 60.0 29.0 18 25 Dd

TA01H1-070 70.0 32.0 20 32 js16 h8 L

TA01H1-080 80.0 35.0 22 32 ±1
