CARTRIDGE / WRENCH BOLT

▶ RBC-CC

Group Code No. Insert 미세조정볼트(M) Screw Driver For Head
RBH-251437
EMS25 RBC-028036-CC06 CCMT060204 M0306SS TSB-25055 T-8 RBH-321844
EMS32 RBC-036047-CC06 M0408SS TSB-35080 T-15 RBH-402250
EMS40 RBC-047060-CC09 CCMT09T308 M0410SS RBH-502855
EMS50 RBC-060076-CC12 M0514SS TSB-50125 T-20 RBH-633660
EMS63 RBC-076098-CC12 CCMT120408 M0515SS RBH-804576
EMS80 RBC-098125-CC12 M0620SS
For Head
▶ RBC-SC RBH-251437
RBH-321844
Group Code No. Insert 미세조정볼트(M) Screw Driver RBH-402250
RBH-502855
EMS25 RBC-028036-SC06 SCMT060204 M0306SS TSB-25055 T-8 RBH-633660
EMS32 RBC-036047-SC06 SCMT09T308 M0408SS TSB-35080 T-15 RBH-804576
EMS40 RBC-047060-SC09 M0410SS TSB-50125
EMS50 RBC-060076-SC12 SCMT120408 M0514SS T-20
EMS63 RBC-076098-SC12 M0515SS
EMS80 RBC-098125-SC12 M0620SS

● Construction System of Screw’s Code No.

ACCESSORIES Code No. Shape Designation Code No. Shape Designation

M ☐ ☐ ☐ ☐ BH 버튼헤드 스크류 M ☐ ☐ ☐ ☐ BH - W 버튼헤드 스크류+와샤
M ☐☐☐☐HC Button Head Button Head

Screw Screw+Washer
헤드캡 스크류+와샤
헤드캡 스크류 M ☐☐☐☐HC - W Headcap Screw
Headcap Screw
+Washer

M ☐☐☐☐SS 셋트 스크류 M ☐☐☐☐SS - H 셋트 스크류 홀관통
Set Screw Set Screw Hole

M ☐☐☐☐CP 콘포인트 스크류 M☐☐☐☐☐☐-☐
Cornpoint
Screw M size Length Shape Note(etc.)
