MIRAEPO NC TOTAL TOOLING SYSTEM
▣ NC Sleeve (NCB Type)
NC Sleeve(Hole Type)
(NCB-H 슬리브)
∅D1 ∅D2 M Tap ∅D
B
35 L1
L
규격 D D1 D2 L1 L B M 가격
31,600
NCB25-20H 25 29 20 55 90 12 M5 34,300
38,500
NCB32-25H 32 36 25 42,600
80 115 M6
NCB40-32H 40 44 32 14
NCB50-40H 50 54 40 85 120 M8
Stopper Ring
(스토퍼 링) : STPR
M6 규격 D d1 T 가격
∅d1 ∅D STPR16 16 30 8 9,300
STPR20 20 34 9,600
T STPR25 25 39 9,900
STPR32 32 46 10,100
STPR40 40 54 10,700
STPR50 50 64 11,500
