MIRAEPO NC TOTAL TOOLING SYSTEM
▣ 멀티 터닝 홀더 (Multi Turning Holder)
Fig 1 L D L D
L1 L Fig 4 L D
L L1
Fig 2
L1 D
Fig 5
Fig 3 L1
L1
D
9
규격 Fig D L L1 적용insert 가격
SVVBN2020R-K16-MH 1 25 VBMT1604 52,200
SDNCN2020R-K09-MH 2 DCMT09T
STTCN2020R-K16-MH 3 20 125 20 TCMT16T 55,000
SSDPN2020R-K14-MH 4 25 SPMG1405
SSDPN2020R-K11-MH 5 SPMG1104
SVVBN2525R-M16-MH 1 25 VBMT1604
SDNCN2525R-M09-MH 2 25 150 20 DCMT09T
STTCN2525R-M16-MH 3 TCMT16T
SSDPN2525R-M14-MH 4 25 SPMG1405
SSDPN2525R-M11-MH 5 SPMG1104
