고속 가공 전용
EXCEL series 2F CBN EXCEL CORNER RADIUS END MILL for HARDENEDMATERIALS
2날 CBN 엑셀 코너 R 엔드밀
열처리 금형강 및 그라파이트 정삭 가공용
Applicable finish processing for hardened mold steel and graphite
Materials : CBN
공차 Radius tolerance :+ 0, - 0.005㎜ 단위 unit : ㎜
품명 날경 R 값 유효장 간섭각 날장 자루경 전장
Item Cutting Corner IA Shank Overall
Effective Length Dia length
Dia Radius length of cut
CBNR - 020303 0.3 11°37′ 0.3
0.2 0.03 4 54
020305 0.5 11°23′ 0.5
030503 0.3 11°36′
030508
0.3 0.05 0.3 4 54
0.8 11°
040510 0.05 10°45′
041010
0.4 1 0.4 4 54
0.1 10°45′
050515 0.05 10°44′
051015
0.5 1.5 0.5 4 54
0.1 10°44′
060520 0.05 9°38′
061020
0.6 2 0.6 4 54
0.1 9°38′
081020 0.8 0.1 2 9°31′ 0.8 4 54
* I A : Inclined angle 101020 0.1 9°24′ 54
from edge side to shank corner 102020 1.0 2 0.9 4 54
121030
122030 0.2 9°24′
0.1 8°18′
1.2 3 1.0 4
0.2 9°15′
