고속 가공 전용

EXCEL series 2F EXCEL END MILL for HIGH SPEED MACHINING CENTERS
2날 엑셀 엔드밀

열처리 금형강 및 그라파이트 고속가공용

Applicable for hardened steel and graphite processing
Ti/Al/Si Coated 0.2㎛ Ultra fine micro grain tungsten carbide

공차 Tolerance :+ 0, - 0.005㎜ 단위 unit : ㎜

품명 날경 유효장 날장 자루경 전장
Cutting Effective Length
Item of cut Shank Overall
Dia length Dia length
2 CES-0.1 ø 0.2 0.1 0.2 0.2
0.1 ø 0.4 0.4 0.4 4 40
0.2 ø 0.5 0.2 0.5 0.5
0.2 ø 1 1 0.3 4 40
0.2 ø 1.5 0.3 1.5
0.2 ø 2 2 0.4 4 40
0.3 ø 1 1
0.3 ø 1.5 1.5 0.5
0.3 ø 2 2
0.3 ø 3 3 0.6
0.4 ø 1 1
2 0.7
0.4 ø 2 0.4 3 4 45
0.4 ø 3 0.5 4
0.4 ø 4 0.6 5 4 45
0.4 ø 5 6
0.4 ø 6 2 4 45
0.5 ø 2 3
0.5 ø 3 4
0.5 ø 4 5
0.5 ø 5 6
0.5 ø 6 8
0.5 ø 8 2
0.6 ø 2 3
0.6 ø 3 4
0.6 ø 4 5
0.6 ø 5 6
0.6 ø 6 8
0.6 ø 8 10
0.6 ø 10
