고속 가공 전용

EXCEL series 4F EXCEL END MILL for HIGHSPEED MACHINING CENTERS
4날 엑셀 엔드밀

열처리 금형강 및 그라파이트 고속가공용

Applicable for hardened steel and graphite processing
Ti/Al/Si Coated 0.2㎛ Ultra fine micro grain tungsten carbide

공차 Tolerance :+ 0, - 0.005㎜ 단위 unit : ㎜

품명 날경 유효장 날장 자루경 전장
Cutting Effective Length Shank Overall
Item of cut Dia length
Dia length
4 CES-1.0 ø 4 1.0 4 1.5 4 45
1.0 ø 6 1.2 6
1.2 ø 6 1.5 6 1.8 4 45
1.2 ø 8 1.8 8
1.5 ø 6 6 2.3 4 45
1.5 ø 8 2.0 8
1.8 ø 6 6 2.7 4 45
1.8 ø 8 2.5 8
2.0 ø 4 4 3.0 45
2.0 ø 6 3.0 6 4
2.0 ø 8 8 4.0
2.0 ø 12 4.0 12 3.7 52
2.0 ø 16 5.0 16
2.5 ø 4 6.0 4 4.5 4 45
2.5 ø 8 8.0 8 52
2.5 ø 12 10.0 12 6.0 45
3.0 ø 8 12.0 8 8.0
3.0 ø 12 12 10.0 4
3.0 ø 16 16 11.0 52
3.0 ø 20 20 13.0
4.0 ø 12 12 13.0 4 52
4.0 ø 16 16 13.0
5.0 ø 20 20 16.0 6 63
6.0 ø 19 19 15.0
6.0 ø 25 25 20.0 6 63
8.0 ø 21 21
8.0 ø 30 30 8 63
10.0 ø 23 23 100
10.0 ø 25 25 63
10.0 ø 35 35
12.0 ø 25 25 10 75
12.0 ø 40 40 106

12 80
106
