고속 가공 전용

EXCEL series
2날 엑셀 코너 R 엔드밀

품명 날경 R값 날장 자루경 전장
Cutting Corner Length
Item Radius of cut Shank Overall
Dia Dia length
2 CCR-3.0 ø 0.1R 3.0 0.1 8.0
3.0 ø 0.2R 0.2 6 63
3.0 ø 0.3R 4.0 0.3 10.0
3.0 ø 0.5R 0.5 6 63
4.0 ø 0.1R 5.0 0.1 12.0
4.0 ø 0.2R 0.2 6 75
4.0 ø 0.3R 6.0 0.3 13.0 6 80
4.0 ø 0.5R 0.5 8 100
4.0 ø 1.0R 8.0 1.0 19.0 10 106
5.0 ø 0.2R 0.2
5.0 ø 0.3R 10.0 0.3 22.0 12 106
5.0 ø 0.5R 0.5
5.0 ø 1.0R 12.0 1.0 26.0
6.0 ø 0.2R 0.2
6.0 ø 0.3R 0.3
6.0 ø 0.5R 0.5
6.0 ø 1.0R 1.0
8.0 ø 0.2R 0.2
8.0 ø 0.3R 0.3
8.0 ø 0.5R 0.5
8.0 ø 1.0R 1.0
10.0 ø 0.2R 0.2
10.0 ø 0.3R 0.3
10.0 ø 0.5R 0.5
10.0 ø 1.0R 1.0
12.0 ø 0.2R 0.2
12.0 ø 0.3R 0.3
12.0 ø 0.5R 0.5
12.0 ø 1.0R 1.0
12.0 ø 2.0R 2.0
