   Shrink Fit                   ER NUT & SEALING DISK                                            NUT/DS
Holder

   Milling
Chuck

                                                 ◆ XSQ-RA (외부 나사형)                                          Unit : mm
                                                                                                 LENGTH
   SK Slim                                       MODEL No.               THREAD      Dia.
Chuck                                                                                18.0           6.0
                                                 XSQ-RA11                M18×1.00    24.0           8.0
                                                                                     28.0           11.0
                                                 XSQ-RA16                M24×1.00    32.0           12.5
                                                                                     40.0           14.0
                                                 XSQ-RA20                M28×1.50

   ER Collet                                     XSQ-RA25                M32×1.50
Chuck
                                                 XSQ-RA32                M40×1.50

N&COHDtorhilldel reCTrhsouoclk                   ◆ XSQ-RAT (External Thread/ Sealing Disk Type)             Unit : mm
                                                                                                 LENGTH
                                                 MODEL No.               THREAD      Dia.
                                                                                                    8.0
                                                 XSQ-RA11S*              M18×1.00    18.0           11.0
                                                                                                    12.5
             Morse Taper                         XSQ-RAT16               M24×1.00    24.0           14.0
                                                                                                    17.5
Arbor                                            XSQ-RAT20               M28×1.50    28.0

                                                 XSQ-RAT25               M32×1.50    32.0

                                                 XSQ-RAT32               M40×1.50    40.0

Tapping Chuck                                    * Without sealing disk

             Synchro

                                                 ◆ SEALING DISK                                             Unit : mm

   Tapping ER                                            MODEL No.             Dia.              THICKNESS
Chuck                                                        DS16              13.0                    4.0
                                                             DS20              16.0                   4.0
   Tapping                                                   DS25              21.0                   4.0
Chuck                                                        DS32              27.0                   4.0
                                                             DS40              33.5                   4.0
                                                             DS50              31.0                   4.0

                                     ▶ 재고 관리 제품

   Side Lock Arbor                               ◆ SEALING DISK SET      Dia.        THICKNESS                       Unit : mm
& End Mill Holder                                                        13.0             4.0    SEALING DISKS/SET
                                                         MODEL No.       16.0             4.0
   Face Mill                                                DS16S2       21.0             4.0            7pcs/set
Arbor                                                       DS20S2       27.0             4.0           10pcs/set
                                                            DS25S2       33.5             4.0           13pcs/set
                                                            DS32S2       31.0             4.0           17pcs/set
                                                            DS40S2                                      23pcs/set
                                                            DS50S2                                      22pcs/set

   Shell Mill
Arbor

   Boring
System

   Accessory                    120              TOOL CO., LTD. www.ssktool.co.kr
