MILLING CHUCK C Shrink Fit
Holder
H
Milling
Chuck

d1
D1
SK Slim
Chuck

TAPER No.

L ER Collet
Chuck

CBT Taper G Value RPM Coolant N&COHDtroilhlledreCrThsouoclk
Accuracy - System

CBT (BT 2면 구속형) AT3 - -
Unit : mm
TAPER No. MODEL No. d1 D1 L H Applicable collet 중량(Kg) 재고 Morse TaperArbor
30 CBT30-C20-75 20 54 75 ●
40 CBT30-C25-80 25 62.5 80 70 K20, CK20 1.50 ●
CBT40-C20-80 20 54 80
50 CBT40-C20-105 20 54 105 70 K25, CK25 2.00 ●
CBT40-C25-105 25 62.5 105 ●
CBT40-C32-90 32 72 90 70 K20, CK20 2.00 ●
CBT40-C32-105 32 72 105
CBT40-C32-135 32 72 135 70 K20, CK20 2.10 ● Synchro Tapping Chuck
CBT50-C20-105 20 54 105 ●
CBT50-C20-135 20 54 135 80 K25, CK25 2.50 ●
CBT50-C20-165 20 54 165 ●
CBT50-C25-105 25 62.5 105 100 K32, CK32 3.00
CBT50-C25-135 25 62.5 135
CBT50-C25-165 25 62.5 165 100 K32, CK32 3.10
CBT50-C32-105 32 72 105
CBT50-C32-115 32 72 115 100 K32, CK32 3.30 Tapping ER
CBT50-C32-135 32 72 135 Chuck
CBT50-C32-165 32 72 165 70 K20, CK20 4.50
CBT50-C42-115 42 92 115
CBT50-C42-135 42 92 135 70 K20, CK20 4.90
CBT50-C42-165 42 92 165
70 K20, CK20 5.40

80 K25, CK25 5.20

80 K25, CK25 5.80 Tapping
Chuck
80 K25, CK25 6.20

100 K32, CK32 6.00

100 K32, CK32 6.20

100 K32, CK32 6.70 Side Lock Arbor
& End Mill Holder
100 K32, CK32 7.40

110 K42, CK42 6.70

110 K42, CK42 7.60

110 K42, CK42 8.30

▶ Collet 및 Spanner 적용범위 76page 참고 Face Mill
