[ WB512 series ] 9
합금강, 탄소강 프리하든강 고경도강 > Technical Data
피삭재 Alloy Steels Carbon Steels Prehardened Steels Hardened Steels 추천절삭조건표
(SCM, SNCM, S45C) (NAK, CENA, KP4) (SKD, SKT, STAVAX)
경도
~HRc35 HRc35~HRc45 HRc45~HRc55
강도 ~1100N/mm2 1100~1500N/mm2 1500~2000N/mm2
외경(mm) 유효길이 RPM FEED Ap(mm) RPM FEED Ap(mm) RPM FEED Ap(mm)
1.5 10 21,510 1,280 0.054 20,340 1,100 0.042 18,000 870 0.030
1.5 12
1.5 14 21,510 1,280 0.054 20,340 1,100 0.042 18,000 870 0.030
1.5 16
1.5 18 21,510 1,280 0.034 20,340 1,100 0.026 18,000 870 0.019
1.5 20
1.5 22 19,120 1,010 0.034 18,080 865 0.026 16,000 690 0.019
1.5 26
1.5 30 19,120 1,010 0.034 18,080 865 0.026 16,000 690 0.019
1.5 35
1.5 40 19,120 1,010 0.020 18,080 865 0.016 16,000 690 0.011
1.6 4
1.6 6 19,120 1,010 0.020 18,080 865 0.016 16,000 690 0.011
1.6 8
1.6 10 14,340 665 0.014 13,560 570 0.011 12,000 450 0.008
1.6 12
1.6 16 14,340 665 0.014 13,560 570 0.011 12,000 450 0.008
1.6 20
1.8 4 7,170 285 0.010 6,780 245 0.008 6,000 195 0.005
1.8 6
1.8 8 7,170 285 0.010 6,780 245 0.008 6,000 195 0.005
1.8 10
1.8 12 22,200 1,555 0.101 21,000 1,300 0.078 18,500 1,110 0.056
1.8 16
1.8 20 22,200 1,555 0.101 21,000 1,300 0.078 18,500 1,110 0.056
2.0 6
2.0 8 22,200 1,555 0.101 21,000 1,300 0.078 18,500 1,110 0.056
2.0 10
2.0 12 19,980 1,260 0.058 18,900 1,055 0.045 16,650 900 0.032
2.0 14
2.0 16 19,980 1,260 0.058 18,900 1,055 0.045 16,650 900 0.032
2.0 18
2.0 20 19,980 1,260 0.036 18,900 1,055 0.028 16,650 900 0.020
2.0 22
2.0 26 17,760 995 0.036 16,800 830 0.028 14,800 710 0.020
2.0 30
2.0 35 22,200 1,780 0.113 21,000 1,470 0.088 18,500 1,225 0.063
2.0 40
2.0 45 22,200 1,780 0.113 21,000 1,470 0.088 18,500 1,225 0.063
2.0 50
2.0 60 22,200 1,780 0.113 21,000 1,470 0.088 18,500 1,225 0.063
2.5 8
2.5 10 19,980 1,440 0.065 18,900 1,190 0.050 16,650 990 0.036
2.5 12
2.5 16 19,980 1,440 0.065 18,900 1,190 0.050 16,650 990 0.036
2.5 20
2.5 22 19,980 1,440 0.041 18,900 1,190 0.032 16,650 990 0.023
2.5 26
2.5 30 17,760 1,140 0.041 16,800 940 0.032 14,800 785 0.023
2.5 35
2.5 40 18,000 1,795 0.180 17,000 1,525 0.140 15,000 1,285 0.100
2.5 45
2.5 50 18,000 1,795 0.126 17,000 1,525 0.098 15,000 1,285 0.070
18,000 1,795 0.126 17,000 1,525 0.098 15,000 1,285 0.070
16,200 1,455 0.072 15,300 1,235 0.056 13,500 1,040 0.040
16,200 1,455 0.072 15,300 1,235 0.056 13,500 1,040 0.040
16,200 1,455 0.072 15,300 1,235 0.056 13,500 1,040 0.040
16,200 1,455 0.045 15,300 1,235 0.035 13,500 1,040 0.025
16,200 1,455 0.045 15,300 1,235 0.035 13,500 1,040 0.025
14,400 1,150 0.045 13,600 975 0.035 12,000 820 0.025
14,400 1,150 0.045 13,600 975 0.035 12,000 820 0.025
14,400 1,150 0.027 13,600 975 0.021 12,000 820 0.015
10,800 755 0.018 10,200 640 0.014 9,000 540 0.010
10,800 755 0.018 10,200 640 0.014 9,000 540 0.010
5,400 325 0.018 5,100 275 0.014 4,500 230 0.010
5,400 325 0.018 5,100 275 0.014 4,500 230 0.010
5,400 325 0.018 5,100 275 0.014 4,500 230 0.010
15,800 1,925 0.158 14,900 1,605 0.123 13,200 1,305 0.088
15,800 1,925 0.158 14,900 1,605 0.123 13,200 1,305 0.088
15,800 1,925 0.158 14,900 1,605 0.123 13,200 1,305 0.088
14,220 1,560 0.090 13,410 1,300 0.070 11,880 1,055 0.050
14,220 1,560 0.090 13,410 1,300 0.070 11,880 1,055 0.050
14,220 1,560 0.056 13,410 1,300 0.044 11,880 1,055 0.031
12,640 1,230 0.056 11,920 1,025 0.044 10,560 835 0.031
12,640 1,230 0.056 11,920 1,025 0.044 10,560 835 0.031
12,640 1,230 0.034 11,920 1,025 0.026 10,560 835 0.019
9,480 810 0.034 8,940 675 0.026 7,920 550 0.019
9,480 810 0.023 8,940 675 0.018 7,920 550 0.013
9,480 810 0.023 8,940 675 0.018 7,920 550 0.013
RPM=rev./min.
FEED=mm/min.
