2

고경도용 엔드밀 자무스스타
TEANPDSMILLS
4날
> Metric & Inch 고경도 고속가공
리브 롱 넥 엔드밀
θ Ød1

Ød3 ØD
L1

L2
L3

ZSLNS40....-.. series ULTRA FINE 30 절삭조건

HELIX p.968

EDP. No. 규 격(mm) 유효길이

고경도용 엔드밀 - 자무스 스타 시리즈 ZSLNS4010-4 D L2 L1 d1 L3 d3 θ 0.5° 1° 1.5° 2° 3°
ZSLNS4010-6
ZSLNS4010-8 4 7.7 5.1 5.5 5.8 6.1 6.6
ZSLNS4010-10
ZSLNS4015-4 1 6 1.5 0.96 50 4 6.6 7.2 7.7 8.1 8.4 9.1
ZSLNS4015-6 8 5.7 9.4 9.9 10.4 10.7 11.4
ZSLNS4015-8
ZSLNS4015-10 10 5.0 11.5 12.1 12.6 13.0 13.7
ZSLNS4015-12
ZSLNS4015-14 4 7.2 5.2 5.5 5.9 6.2 6.7
ZSLNS4015-16
ZSLNS4015-18 6 50 6.0 7.3 7.8 8.1 8.5 9.1
ZSLNS4015-20 8 5.1 9.4 10.0 10.4 10.8 11.5
ZSLNS4015-25
ZSLNS4020-4 10 4.5 11.6 12.1 12.6 13.0 13.8
ZSLNS4020-6
ZSLNS4020-8 1.5 12 2.25 1.44 55 4 4.0 13.7 14.3 14.8 15.3 16.1
ZSLNS4020-10 14 3.6 15.8 16.5 17.0 17.5 18.7
ZSLNS4020-12
ZSLNS4020-14 16 3.3 17.9 18.6 19.2 19.7 -
ZSLNS4020-16
ZSLNS4020-18 18 60 3.0 20.0 20.7 21.3 21.9 -
ZSLNS4020-20 20 2.8 22.0 22.9 23.5 24.1 -
ZSLNS4020-25
ZSLNS4020-30 25 65 2.4 27.3 28.1 28.8 30.0 -
ZSLNS4025-8
ZSLNS4025-10 4 6.5 5.3 5.6 5.9 6.2 6.7
ZSLNS4025-12
ZSLNS4025-14 6 50 5.3 7.4 7.8 8.2 8.5 9.1
ZSLNS4025-16 8 4.5 9.5 10.0 10.4 10.8 11.5
ZSLNS4025-18
ZSLNS4025-20 10 3.9 11.6 12.2 12.7 13.1 13.8
ZSLNS4025-25 12 3.4 13.7 14.3 14.9 15.3 16.1
ZSLNS4025-30
2 14 3 1.92 55 4 3.1 15.8 16.5 17.0 17.5 18.8
- 무간섭
16 2.8 17.9 18.6 19.2 19.7 -

18 60 2.6 20.0 20.8 21.4 21.9 -
20 2.4 22.1 22.9 23.5 24.1 -

25 65 2.0 27.3 28.2 28.9 - -

30 70 1.7 32.5 33.4 34.4 - -

8 50 3.7 9.6 10.1 10.5 10.9 11.5
10 3.1 11.7 12.2 12.7 13.1 13.8

12 2.7 13.8 14.4 14.9 15.3 -

14 55 2.4 15.9 16.5 17.1 17.5 -

2.5 16 3.75 2.4 4 2.2 18.0 18.7 19.2 19.7 -

18 60 2.0 20.1 20.8 21.4 - -
20 1.8 22.1 22.9 23.5 - -

25 65 1.5 27.3 28.2 - - -

30 70 1.3 32.6 33.5 - - -

다음페이지에 계속
