P일D반S .가..se공rie용s 드릴 파워 드릴 3

▶3xD 절삭조건
140°
ULTRA FINE HELIX > Metric & Inch
p.1034
DRILLS
EDP. No. D L1 L2 D2 EDP. No. D L1 L2 D2
PDS141 14.1
PDS094 9.4 PDS142 14.2
PDS143 14.3
PDS095 9.5 PDS144 14.4
PDS145 14.5
PDS096 9.6 PDS146 14.6
PDS147 14.7
PDS097 9.7 47 89 10 PDS148 14.8
PDS098 9.8 PDS149 14.9
PDS150 15.0 62 111 15
PDS099 9.9 PDS151 15.1
PDS152 15.2
PDS100 10.0 PDS154 15.4
PDS155 15.5
PDS101 10.1 PDS156 15.6
PDS157 15.7
PDS102 10.2 PDS158 15.8
PDS159 15.9
PDS103 10.3 PDS160 16.0
PDS161 16.1
PDS104 10.4 PDS163 16.3
PDS164 16.4
PDS105 10.5 51 95 11 PDS165 16.5
PDS106 10.6 PDS170 17.0
PDS171 17.1
PDS107 10.7 PDS172 17.2
PDS173 17.3
PDS108 10.8 PDS175 17.5 64 115 16
PDS177 17.7
PDS109 10.9 PDS178 17.8 66 119 17
PDS180 18.0
PDS110 11.0 PDS181 18.1 66 123 18
PDS182 18.2
PDS111 11.1 PDS185 18.5 70 127 19
PDS190 19.0
PDS112 11.2 PDS191 19.1 70 131 20
PDS192 19.2 75 131 22
PDS113 11.3 PDS195 19.5 80 131 23
PDS197 19.7 86 140 23
PDS114 11.4 PDS200 20.0 86 140 24
PDS220 22.0
PDS115 11.5 54 102 12 PDS225 22.5
PDS116 11.6 PDS230 23.0
PDS235 23.5
PDS117 11.7 PDS240 24.0

PDS118 11.8

PDS119 11.9

PDS120 12.0

PDS121 12.1

PDS122 12.2

PDS123 12.3

PDS124 12.4

PDS125 12.5 57 102 13
PDS126 12.6

PDS127 12.7

PDS128 12.8

PDS129 12.9

PDS130 13.0

PDS131 13.1

PDS132 13.2

PDS133 13.3

PDS132 13.4

PDS135 13.5 60 107 14 알번가공용 드릴 - 파워 드릴 시리즈
PDS136 13.6

PDS137 13.7

PDS138 13.8

PDS139 13.9

PDS140 14.0

■적용 피삭재 합금강 프리하든강 열처리강 동 흑연 주철 알루미늄 스테인리스강
(SCM, SK...) (NAK...) FCD400. 500~
탄소강 HB225~325 ~HRc55 SKD61 ~HRc55 SKD11 ◎
(S45C, S55C...) HRc30~50
◎ ○○ ◎ ○:적합 ◎:매우적합
~ HB225 ◎

○

■허용공차 1이상 3이하 3초과 6이하 6초과 10이하 10초과 18이하 ㎛=1/1000㎜
공차 외경
0 0 0 0 18초과 30이하
인선부(h8) -14 -18 -22 -27 0
0 0 0 0 -33
생크부(h6) -6 -8 -9 -11 0
-13
