P일D반M 가...s공eri용es 드릴 파워 드릴 3

▶5xD 절삭조건
140°
ULTRA FINE HELIX > Metric & Inch
p.1034
DRILLS
EDP. No. D L1 L2 D2 EDP. No. D L1 L2 D2
14.1
PDM104 10.4 PDM141 14.2
PDM142 14.3
PDM105 10.5 PDM143 14.4
PDM144 14.5
PDM106 10.6 PDM145 14.6
PDM146 14.7
PDM107 10.7 68 115 11 PDM147 14.8
PDM148 14.9
PDM108 10.8 PDM149 15.0 83 143 15
PDM150 15.1
PDM109 10.9 PDM151 15.2
PDM152 15.4
PDM110 11.0 PDM154 15.5
PDM155 15.6
PDM111 11.1 PDM156 15.7
PDM157 15.8
PDM112 11.2 PDM158 16.0
PDM160 16.1
PDM113 11.3 PDM161 16.3
PDM163 16.5
PDM114 11.4 PDM165 17.0
PDM170 17.1
PDM115 11.5 71 121 12 PDM171 17.2
PDM116 11.6 PDM172 17.5
PDM175 17.7
PDM117 11.7 PDM177 17.8 90 152 16
PDM178 18.0
PDM118 11.8 PDM180 18.1
PDM181 18.2
PDM119 11.9 PDM182 18.5
PDM185 19.0
PDM120 12.0 PDM190 19.1
PDM191 19.5
PDM121 12.1 PDM195 19.7
PDM197 20.0
PDM122 12.2 PDM200

PDM123 12.3 95 155 17

PDM124 12.4

PDM125 12.5 75 125 13
PDM126 12.6

PDM127 12.7

PDM128 12.8 100 157 18

PDM129 12.9

PDM130 13.0

PDM131 13.1

PDM132 13.2

PDM133 13.3 105 160 19

PDM134 13.4

PDM135 13.5 80 134 14
PDM136 13.6

PDM137 13.7 110 163 20

PDM138 13.8

PDM139 13.9

PDM140 14.0

■적용 피삭재 합금강 프리하든강 열처리강 동 흑연 주철 알루미늄 스테인리스강 알번가공용 드릴 - 파워 드릴 시리즈
(SCM, SK...) (NAK...) FCD400. 500~
탄소강 HB225~325 ~HRc55 SKD61 ~HRc55 SKD11 ◎
(S45C, S55C...) HRc30~50
◎ ○○ ◎ ○:적합 ◎:매우적합
~ HB225 ◎

○

■허용공차 1이상 3이하 3초과 6이하 6초과 10이하 10초과 18이하 ㎛=1/1000㎜
공차 외경
0 0 0 0 18초과 30이하
인선부(h8) -14 -18 -22 -27 0
0 0 0 0 -33
생크부(h6) -6 -8 -9 -11 0
-13
