일반가공용 드릴PDMI ...series 3

파워 드릴 HELIX ▶5xD 절삭조건 > Metric & Inch
140°
ULTRA FINE L1 DRILLS
h8 p.1034
EDP. No. D L1 L2 D2 EDP. No. D
14.1 L2 D2
PDMI141 14.2
PDMI105 10.5 PDMI142 14.3
PDMI143 14.4
PDMI106 10.6 PDMI144 14.5
PDMI145 14.6
PDMI107 10.7 68 125 11 PDMI146 14.7
PDMI108 10.8 PDMI147 14.8
PDMI148 14.9
PDMI109 10.9 PDMI149 15.0 83 148 15
PDMI150 15.1
PDMI110 11.0 PDMI151 15.2
PDMI152 15.4
PDMI111 11.1 PDMI154 15.5
PDMI155 15.6
PDMI112 11.2 PDMI156 15.7
PDMI157 15.8
PDMI113 11.3 PDMI158 16.0
PDMI160 16.1
PDMI114 11.4 PDMI161 16.3
PDMI163 16.5
PDMI115 11.5 71 133 12 PDMI165 17.0
PDMI116 11.6 PDMI170 17.1
PDMI171 17.2
PDMI117 11.7 PDMI172 17.5
PDMI175 17.7
PDMI118 11.8 PDMI177 17.8 90 152 16
PDMI178 18.0
PDMI119 11.9 PDMI180 18.1
PDMI181 18.2
PDMI120 12.0 PDMI182 18.5
PDMI185 19.0
PDMI121 12.1 PDMI190 19.1
PDMI191 19.5
PDMI122 12.2 PDMI195 19.7
PDMI197 20.0
PDMI123 12.3 PDMI200

PDMI124 12.4 95 155 17

PDMI125 12.5 75 137 13
PDMI126 12.6

PDMI127 12.7

PDMI128 12.8

PDMI129 12.9 100 157 18

PDMI130 13.0

PDMI131 13.1

PDMI132 13.2

PDMI133 13.3

PDMI134 13.4 105 160 19

PDMI135 13.5 80 142 14
PDMI136 13.6

PDMI137 13.7

PDMI138 13.8 110 163 20

PDMI139 13.9

PDMI140 14.0

■적용 피삭재 합금강 프리하든강 열처리강 동 흑연 주철 알루미늄 스테인리스강 알번가공용 드릴 - 파워 드릴 시리즈
(SCM, SK...) (NAK...) FCD400. 500~
탄소강 HB225~325 ~HRc55 SKD61 ~HRc55 SKD11 ◎
(S45C, S55C...) HRc30~50
◎ ○○ ○ ○:적합 ◎:매우적합
~ HB225 ◎

○

■허용공차 1이상 3이하 3초과 6이하 6초과 10이하 10초과 18이하 ㎛=1/1000㎜
공차 외경
0 0 0 0 18초과 30이하
인선부(h8) -14 -18 -22 -27 0
0 0 0 0 -33
생크부(h6) -6 -8 -9 -11 0
-13
