9

[ TXB202, 222, 232, 302 ...series ]

피삭재 탄소강, 합금강, 공구강 열처리강 주철 알루미늄합금 > Technical Data

경도 ~ HRc30 HRc30 ~ HRc45 HRc45 ~ HRc50 추천절삭조건표

강도 ~ 1000N/mm2 1000 ~ 1500N/mm2 1500N/mm2

외경(mm) RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED
2 10,500 220 30,800 395
3 12,350 640 9,150 415 4,000 125 7,050 230 20,500 395
4 5,150 285 15,400 395
5 11,400 575 8,550 390 3,800 125 4,150 330 12,100 470
6 3,400 360 10,300 470
8 8,950 630 7,150 450 3,600 150 2,500 460 7,900 540
10 2,050 460 6,150 540
12 7,800 700 6,200 490 3,100 150 1,750 460 5,150 630
14 1,400 460 4,300 630
16 7,250 870 5,900 705 2,700 160 1,300 460 3,850 540
18 1,100 460 3,400 540
20 6,100 1,090 4,900 785 2,050 190 1,050 420 2,950 540

5,450 1,330 4,350 870 1,750 190

4,990 1,500 3,950 950 1,500 210

4,530 1,495 3,600 925 1,300 210

4,085 1,470 3,200 905 1,150 210

3,800 1,425 3,000 890 1,050 210

3,550 1,425 2,800 885 950 210

RPM = rev. / min.
FEED = mm / min.

Ae 0.3D

Ae : D1~D6=0.2mm Ap 0.7D
D8~D20=0.3mm

Ap : 0.2D

※ 롱 또는 엑스트라 롱 시리즈는 절삭속도를 30~40% 줄여 사용하십시오.

[ TXB304, TXB204 ...series ]

피삭재 합금강, 공구강 열처리강 주철 알루미늄합금

경도 ~ HRc30 HRc30 ~ HRc45 HRc45 ~ HRc50

강도 ~ 1000N/mm2 1000 ~ 1500N/mm2 1500N/mm2

외경(mm) RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED
13,100 300 38,500 600
2 15,400 1,000 11,400 600 5,000 200 8,800 300 25,600 600
3 6,400 400 19,300 600
4 14,300 900 10,700 600 4,800 200 5,200 500 15,100 700
5 4,300 500 12,900 700
6 11,200 900 8,900 700 4,500 200 3,100 700 9,900 800
8 2,600 700 7,700 800
10 9,800 1,100 7,800 700 3,900 200 2,200 700 6,400 900
12 1,800 700 5,400 900
14 9,100 1,300 7,400 1,100 3,400 200 1,600 700 4,800 800
16 1,400 700 4,300 800
18 7,600 1,600 6,100 1,200 2,600 300 1,300 600 3,700 800
20
6,800 2,000 5,400 1,300 2,200 300

6,200 2,300 4,900 1,400 1,900 300

5,700 2,200 4,500 1,400 1,600 300

5,100 2,200 4,000 1,400 1,400 300

4,800 2,100 3,800 1,300 1,300 300

4,400 2,100 3,500 1,300 1,200 300

989
