2 Flutes High Speed Standard Length Ball End Mills

2

HARD series Endmills for pre-hardened and hardened steel (HRc50~62)

Good wear resistance by Si-based PVD coating.

High precise edge tolerance.

Very nice work surface finish.

Outstanding performance at high speed machining by ultra fine

(0.2 ) WC grade.

D Size D Tolerance

0.06 ~ 0.19 +0 ~ -0.005mm

0.2 ~ 5.8 +0 ~ -0.01mm

6 ~ 12 -0.005 ~ -0.015mm

0.005 0.01 0.015 13 ~ 20 -0.01 ~ -0.02mm
6.5 ~ 10R
0.03 ~2.93R 3 ~ 6R mm

Order Number Diameter Length Overall Shank Order Number Diameter Length Overall Shank
RD of cut Length Dia of cut Length Dia
2HCB 0006 001 S04 2HCB 030 080 S06 RD L1 L d
2HCB 0007 0012 S04 L1 L d 2HCB 030 080 080
2HCB 0008 0015 S04 2HCB 030 080 100 1.5R X 3 8 60 6
2HCB 0009 0017 S04 0.03R X 0.06 0.1 40 4 2HCB 032 080 S04 1.5R X 3 8 80 6
2HCB 001 002 S04 0.035R X 0.07 0.12 40 4 2HCB 034 080 S04 1.5R X 3 8 100 6
2HCB 0015 003 S04 0.04R X 0.08 0.15 40 4 2HCB 035 080 S06 1.6R X 3.2 8 60 4
2HCB 002 004 S04 0.045R X 0.09 0.17 40 4 2HCB 036 090 S04 1.7R X 3.4 8 60 4
2HCB 003 006 S04 0.05R X 0.1 0.2 40 4 2HCB 038 090 S04 1.75R X 3.5 8 60 6
2HCB 004 008 S04 0.075R X 0.15 0.3 40 4 2HCB 040 080 060 1.8R X 3.6 9 60 4
2HCB 005 010 S04 0.1R X 0.2 0.4 40 4 2HCB 040 080 080 1.9R X 3.8 9 60 4
2HCB 006 012 S04 0.15R X 0.3 0.6 40 4 2HCB 040 080 S06 2R X 4 8 60 4
2HCB 007 015 S04 0.2R X 0.4 0.8 40 4 2HCB 040 080 090 2R X 4 8 80 4
2HCB 008 020 S04 0.25R X 0.5 4 2HCB 040 080 120 2R X 4 8 70 6
2HCB 009 020 S04 0.3R X 0.6 1 45 4 2HCB 042 100 S06 2R X 4 8 90 6
2HCB 010 025 S03 0.35R X 0.7 1.2 45 4 2HCB 044 100 S06 2R X 4 8 120 6
2HCB 010 025 S04 0.4R X 0.8 1.5 45 4 2HCB 045 080 S06 2.1R X 4.2 10 70 6
2HCB 010 025 S06 0.45R X 0.9 2 45 4 2HCB 046 100 S06 2.2R X 4.4 10 70 6
2HCB 010 025 070 0.5R X 1 2 45 3 2HCB 048 110 S06 2.25R X 4.5 8 70 6
2HCB 010 025 100 0.5R X 1 2.5 50 4 2HCB 050 080 S05 2.3R X 4.6 10 70 6
2HCB 011 027 S04 0.5R X 1 2.5 50 6 2HCB 050 100 S06 2.4R X 4.8 11 70 6
2HCB 012 030 S03 0.5R X 1 2.5 50 6 2HCB 052 120 S06 2.5R X 5 8 80 5
2HCB 012 030 S04 0.5R X 1 2.5 70 6 2HCB 054 120 S06 2.5R X 5 10 75 6
2HCB 013 032 S04 0.55R X 1.1 2.5 100 4 2HCB 055 100 S06 2.6R X 5.2 12 75 6
2HCB 014 035 S04 0.6R X 1.2 2.7 50 3 2HCB 056 120 S06 2.7R X 5.4 12 75 6
2HCB 015 040 S03 0.6R X 1.2 3 50 4 2HCB 058 120 S06 2.75R X 5.5 10 75 6
2HCB 015 040 S04 0.65R X 1.3 3 50 4 2HCB 060 100 060 2.8R X 5.6 12 75 6
2HCB 015 040 S06 0.7R X 1.4 3.2 50 4 2HCB 060 120 080 2.9R X 5.8 12 75 6
2HCB 015 040 070 0.75R X 1.5 3.5 50 3 2HCB 060 120 100 3R X 6 10 60 6
2HCB 015 040 100 0.75R X 1.5 4 50 4 2HCB 060 120 120 3R X 6 12 80 6
2HCB 016 040 S04 0.75R X 1.5 4 50 6 2HCB 060 120 150 3R X 6 12 100 6
2HCB 017 042 S04 0.75R X 1.5 4 50 6 2HCB 070 140 S08 3R X 6 12 120 6
2HCB 018 045 S04 0.75R X 1.5 4 70 6 2HCB 080 140 090 3R X 6 12 150 6
2HCB 019 047 S04 0.8R X 1.6 4 100 4 2HCB 080 140 110 3.5R X 7 14 80 8
2HCB 020 050 S03 0.85R X 1.7 4 50 4 2HCB 080 140 150 4R X 8 14 90 8
2HCB 020 050 S04 0.9R X 1.8 4.2 50 4 2HCB 090 160 S10 4R X 8 14 110 8
2HCB 020 050 S06 0.95R X 1.9 4.5 50 4 2HCB 100 180 100 4R X 8 14 150 8
2HCB 020 050 075 1R X 2 4.7 50 3 2HCB 100 180 120 4.5R X 9 16 100 10
2HCB 020 050 100 1R X 2 5 50 4 2HCB 100 180 150 5R X 10 18 100 10
2HCB 022 055 S04 1R X 2 5 50 6 2HCB 100 180 180 5R X 10 18 120 10
2HCB 024 060 S04 1R X 2 5 50 6 2HCB 110 200 S12 5R X 10 18 150 10
2HCB 025 060 S03 1R X 2 5 75 6 2HCB 120 220 110 5R X 10 18 180 10
2HCB 025 060 S04 1.1R X2.2 5 100 4 2HCB 120 220 130 5.5R X 11 20 110 12
2HCB 025 060 S06 1.2R X2.4 5.5 50 4 2HCB 120 220 150 6R X 12 22 110 12
2HCB 025 060 100 1.25R X 2.5 6 50 3 2HCB 120 220 200 6R X 12 22 130 12
2HCB 026 060 S04 1.25R X 2.5 6 50 4 2HCB 130 240 S14 6R X 12 22 150 12
2HCB 028 070 S04 1.25R X 2.5 6 50 6 2HCB 140 240 S14 6R X 12 22 200 12
2HCB 030 080 S03 1.25R X 2.5 6 75 6 2HCB 160 300 130 6.5R X 13 24 110 14
2HCB 030 080 S04 1.3R X 2.6 6 100 4 2HCB 160 300 160 7R X 14 24 110 14
1.4R X 2.8 6 50 4 8R X 16 30 130 16
1.5R X 3 7 50 3 8R X 16 30 160 16
1.5R X 3 8 60 4
8 50
