4 Flutes High Speed Rib End Mills

4

Endmills for pre-hardened and hardened steel (HRc50~60) HARD series
Good wear resistance by Si-based PVD coating.
High precise edge tolerance.
Reinforced edge design for preventing edge chipping.
Outstanding performance at high speed machining by ultra fine
(0.2 ) WC grade.

0 0.01 0.01 0.025 D Size D Tolerance
0.8 ~ 5 +0 ~ -0.01mm
6 ~ 12 -0.01 ~ -0.025mm

0.8 ~ 5 6 ~ 12 Shield Edge mm

Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia of cut Length Length Dia
4HRE 008 020 S04 D L1 L2 L d 4HRE 025 120 S04 D L1 L2 L d
4HRE 008 040 S04 4HRE 025 160 S04
4HRE 008 060 S04 0.8 0.8 2 45 4 4HRE 025 200 S04 2.5 2.5 12 45 4
4HRE 008 080 S04 0.8 0.8 4 45 4 4HRE 025 250 S04 2.5 2.5 16 50 4
4HRE 008 100 S04 0.8 0.8 6 45 4 4HRE 025 300 S04 2.5 2.5 20 50 4
4HRE 008 120 S04 0.8 0.8 8 45 4 4HRE 030 060 S06 2.5 2.5 25 60 4
4HRE 008 160 S04 0.8 0.8 10 45 4 4HRE 030 080 S06 2.5 2.5 30 70 4
4HRE 009 020 S04 0.8 0.8 12 45 4 4HRE 030 100 S06 3 3 6 45 6
4HRE 009 060 S04 0.8 0.8 16 50 4 4HRE 030 120 S06 3 3 8 45 6
4HRE 009 080 S04 0.9 0.9 2 45 4 4HRE 030 160 S06 3 3 10 45 6
4HRE 009 100 S04 0.9 0.9 6 45 4 4HRE 030 200 S06 3 3 12 50 6
4HRE 010 020 S04 0.9 0.9 8 45 4 4HRE 030 250 S06 3 3 16 55 6
4HRE 010 030 S04 0.9 0.9 10 45 4 4HRE 030 300 S06 3 3 20 60 6
4HRE 010 040 S04 1 1 2 45 4 4HRE 030 350 S06 3 3 25 65 6
4HRE 010 060 S04 1 1 3 45 4 4HRE 030 400 S06 3 3 30 70 6
4HRE 010 080 S04 1 1 4 45 4 4HRE 040 060 S06 3 3 35 75 6
4HRE 010 100 S04 1 1 6 45 4 4HRE 040 080 S06 3 3 40 80 6
4HRE 010 120 S04 1 1 8 45 4 4HRE 040 100 S06 4 4 6 50 6
4HRE 010 140 S04 1 1 10 45 4 4HRE 040 120 S06 4 4 8 50 6
4HRE 010 160 S04 1 1 12 45 4 4HRE 040 160 S06 4 4 10 50 6
4HRE 010 200 S04 1 1 14 50 4 4HRE 040 200 S06 4 4 12 50 6
4HRE 010 250 S04 1 1 16 50 4 4HRE 040 250 S06 4 4 16 55 6
4HRE 012 040 S04 1 1 20 50 4 4HRE 040 300 S06 4 4 20 60 6
4HRE 012 060 S04 1 1 25 60 4 4HRE 040 400 S06 4 4 25 65 6
4HRE 012 080 S04 1.2 1.2 4 45 4 4HRE 040 450 S06 4 4 30 70 6
4HRE 012 100 S04 1.2 1.2 6 45 4 4HRE 040 500 S06 4 4 40 80 6
4HRE 012 120 S04 1.2 1.2 8 45 4 4HRE 050 160 S06 4 4 45 90 6
4HRE 012 160 S04 1.2 1.2 10 45 4 4HRE 050 200 S06 4 4 50 100 6
4HRE 015 040 S04 1.2 1.2 12 45 4 4HRE 050 250 S06 5 5 16 55 6
4HRE 015 060 S04 1.2 1.2 16 50 4 4HRE 050 300 S06 5 5 20 60 6
4HRE 015 080 S04 1.5 1.5 4 45 4 4HRE 050 400 S06 5 5 25 65 6
4HRE 015 100 S04 1.5 1.5 6 45 4 4HRE 050 500 S06 5 5 30 70 6
4HRE 015 120 S04 1.5 1.5 8 45 4 4HRE 060 200 S06 5 5 40 80 6
4HRE 015 160 S04 1.5 1.5 10 45 4 4HRE 060 300 S06 5 5 50 100 6
4HRE 015 200 S04 1.5 1.5 12 45 4 4HRE 060 400 S06 6 6 20 60 6
4HRE 015 250 S04 1.5 1.5 16 50 4 4HRE 060 500 S06 6 6 30 75 6
4HRE 020 040 S04 1.5 1.5 20 50 4 4HRE 080 200 S08 6 6 40 80 6
4HRE 020 060 S04 1.5 1.5 25 60 4 4HRE 080 300 S08 6 6 50 90 6
4HRE 020 080 S04 2 2 4 45 4 4HRE 080 400 S08 8 10 20 65 8
4HRE 020 100 S04 2 2 6 45 4 4HRE 100 250 S10 8 10 30 80 8
4HRE 020 120 S04 2 2 8 45 4 4HRE 100 350 S10 8 10 40 100 8
4HRE 020 140 S04 2 2 10 45 4 4HRE 100 450 S10 10 15 25 70 10
4HRE 020 160 S04 2 2 12 45 4 4HRE 120 300 S12 10 15 35 90 10
4HRE 020 180 S04 2 2 14 50 4 4HRE 120 400 S12 10 15 45 110 10
4HRE 020 200 S04 2 2 16 50 4 4HRE 120 500 S12 12 18 30 80 12
4HRE 020 250 S04 2 2 18 50 4 12 18 40 100 12
4HRE 020 300 S04 2 2 20 50 4 12 18 50 120 12
4HRE 025 100 S04 2 2 25 60 4
2 2 30 70 4
2.5 2.5 10 45 4
