2 Flutes High Speed Rib End Mills

2

Endmills for pre-hardened and hardened steel (HRc50~60) HARD series
Good wear resistance by Si-based PVD coating.
High precise edge tolerance.
Reinforced edge design for preventing edge chipping.
Outstanding performance at high speed machining by ultra fine
(0.2 ) WC grade.

0 0.005 0 0.01 0.01 0.025 D Size D Tolerance
0.1 0.2 ~ 5 6 ~ 12 0.1 +0 ~ -0.005mm
+0 ~ -0.01mm
0.2 ~ 5 -0.01 ~ -0.025mm
6 ~ 12

Shield Edge mm

Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia of cut Length Length Dia
2HRE 001 003 S04 D L1 L2 L d 2HRE 007 020 S04 D L1 L2 L d
2HRE 001 005 S04 2HRE 007 040 S04
2HRE 002 005 S04 0.1 0.3 - 40 4 2HRE 007 060 S04 0.7 0.7 2 40 4
2HRE 002 010 S04 0.1 0.5 - 40 4 2HRE 007 080 S04 0.7 0.7 4 40 4
2HRE 002 015 S04 0.2 0.2 0.5 40 4 2HRE 007 100 S04 0.7 0.7 6 40 4
2HRE 002 020 S04 0.2 0.2 1 40 4 2HRE 007 120 S04 0.7 0.7 8 40 4
2HRE 002 025 S04 0.2 0.2 1.5 40 4 2HRE 008 020 S04 0.7 0.7 10 40 4
2HRE 002 030 S04 0.2 0.2 2 40 4 2HRE 008 030 S04 0.7 0.7 12 45 4
2HRE 003 010 S04 0.2 0.2 2.5 40 4 2HRE 008 040 S04 0.8 0.8 2 40 4
2HRE 003 015 S04 0.2 0.2 3 40 4 2HRE 008 050 S04 0.8 0.8 3 40 4
2HRE 003 020 S04 0.3 0.3 1 40 4 2HRE 008 060 S04 0.8 0.8 4 40 4
2HRE 003 025 S04 0.3 0.3 1.5 40 4 2HRE 008 080 S04 0.8 0.8 5 40 4
2HRE 003 030 S04 0.3 0.3 2 40 4 2HRE 008100 S04 0.8 0.8 6 40 4
2HRE 003 035 S04 0.3 0.3 2.5 40 4 2HRE 008120 S04 0.8 0.8 8 40 4
2HRE 003 040 S04 0.3 0.3 3 40 4 2HRE 008140 S04 0.8 0.8 10 40 4
2HRE 003 050 S04 0.3 0.3 3.5 40 4 2HRE 009 060 S04 0.8 0.8 12 45 4
2HRE 004 010 S04 0.3 0.3 4 40 4 2HRE 009 080 S04 0.8 0.8 14 45 4
2HRE 004 015 S04 0.3 0.3 5 40 4 2HRE 009 100 S04 0.9 0.9 6 40 4
2HRE 004 020 S04 0.4 0.4 1 40 4 2HRE 010 020 S04 0.9 0.9 8 40 4
2HRE 004 025 S04 0.4 0.4 1.5 40 4 2HRE 010 030 S04 0.9 0.9 10 40 4
2HRE 004 030 S04 0.4 0.4 2 40 4 2HRE 010 040 S04 1 1 2 45 4
2HRE 004 035 S04 0.4 0.4 2.5 40 4 2HRE 010 050 S04 1 1 3 45 4
2HRE 004 040 S04 0.4 0.4 3 40 4 2HRE 010 060 S04 1 1 4 45 4
2HRE 004 050 S04 0.4 0.4 3.5 40 4 2HRE 010 080 S04 1 1 5 45 4
2HRE 004 060 S04 0.4 0.4 4 40 4 2HRE 010 100 S04 1 1 6 45 4
2HRE 004 080 S04 0.4 0.4 5 40 4 2HRE 010 120 S04 1 1 8 45 4
2HRE 004 100 S04 0.4 0.4 6 40 4 2HRE 010 140 S04 1 1 10 45 4
2HRE 005 010 S04 0.4 0.4 8 40 4 2HRE 010 160 S04 1 1 12 45 4
2HRE 005 020 S04 0.4 0.4 10 40 4 2HRE 010 180 S04 1 1 14 45 4
2HRE 005 030 S04 0.5 0.5 1 40 4 2HRE 010 200 S04 1 1 16 50 4
2HRE 005 040 S04 0.5 0.5 2 40 4 2HRE 010 250 S04 1 1 18 50 4
2HRE 005 050 S04 0.5 0.5 3 40 4 2HRE 010 300 S04 1 1 20 50 4
2HRE 005 060 S04 0.5 0.5 4 40 4 2HRE 012 040 S04 1 1 25 60 4
2HRE 005 080 S04 0.5 0.5 5 40 4 2HRE 012 060 S04 1 1 30 70 4
2HRE 005 100 S04 0.5 0.5 6 40 4 2HRE 012 080 S04 1.2 1.2 4 45 4
2HRE 005 120 S04 0.5 0.5 8 40 4 2HRE 012 100 S04 1.2 1.2 6 45 4
2HRE 005 140 S04 0.5 0.5 10 40 4 2HRE 012 120 S04 1.2 1.2 8 45 4
2HRE 006 010 S04 0.5 0.5 12 45 4 2HRE 012 160 S04 1.2 1.2 10 45 4
2HRE 006 020 S04 0.5 0.5 14 45 4 2HRE 012 200 S04 1.2 1.2 12 45 4
2HRE 006 030 S04 0.6 0.6 1 40 4 2HRE 012 250 S04 1.2 1.2 16 50 4
2HRE 006 040 S04 0.6 0.6 2 40 4 2HRE 012 300 S04 1.2 1.2 20 50 4
2HRE 006 050 S04 0.6 0.6 3 40 4 2HRE 014 060 S04 1.2 1.2 25 60 4
2HRE 006 060 S04 0.6 0.6 4 40 4 2HRE 014 080 S04 1.2 1.2 30 70 4
2HRE 006 080 S04 0.6 0.6 5 40 4 2HRE 014 100 S04 1.4 1.4 6 45 4
2HRE 006 100 S04 0.6 0.6 6 40 4 2HRE 014 140 S04 1.4 1.4 8 45 4
2HRE 006 120 S04 0.6 0.6 8 40 4 2HRE 014 160 S04 1.4 1.4 10 45 4
2HRE 006 140 S04 0.6 0.6 10 40 4 2HRE 014 200 S04 1.4 1.4 14 45 4
2HRE 006 160 S04 0.6 0.6 12 45 4 2HRE 015 040 S04 1.4 1.4 16 50 4
0.6 0.6 14 45 4 1.4 1.4 20 50 4
0.6 0.6 16 45 4 1.5 1.5 4 45 4
