2 Flutes Long Length End Mills

2

Endmill for various work materials, hardened steel(HRc~55), HARD series
pre-hardened steel, tool steel and cast iron
Good wear resistance by Si-based PVD coating.
Improve tool performance by even run-out and tolerance control.
Various flute and overall length design for covering wide range
applications as well as high efficiency machining.
Minimize edge chipping by improving corner strength.

0 0.01 0.01 0.025 0.015 0.03 D Size D Tolerance
1~5 6 ~ 12 14 ~ 25 1~5 +0 ~ -0.01mm
6 ~ 12 -0.01 ~ -0.025mm
-0.015 ~ -0.03mm
14 ~ 25

Shield Edge mm

Order Number Diameter Length Overall Shank Order Number Diameter Length Overall Shank
of cut Length Dia of cut Length Dia
2LEM 010 030 S06 D L1 L d 2LEM 100 350 S10 D L1 L d
2LEM 010 050 S06 2LEM 100 400 S10
2LEM 010 070 S06 1 3 60 6 2LEM 100 450 S10 10 35 90 10
2LEM 010 100 S06 1 5 60 6 2LEM 100 500 S10 10 40 90 10
2LEM 010 120 S06 1 7 60 6 2LEM 100 550 S10 10 45 100 10
2LEM 010 150 S06 1 10 60 6 2LEM 100 600 S10 10 50 100 10
2LEM 015 060 S06 1 12 60 6 2LEM 100 650 S10 10 55 110 10
2LEM 015 075 S06 1 15 60 6 2LEM 100 700 S10 10 60 110 10
2LEM 015 100 S06 1.5 6 60 6 2LEM 120 300 S12 10 65 120 10
2LEM 015 150 S06 1.5 7.5 60 6 2LEM 120 350 110 10 70 120 10
2LEM 015 200 S06 1.5 10 60 6 2LEM 120 400 S12 12 30 90 12
2LEM 020 060 S06 1.5 15 60 6 2LEM 120 450 S12 12 35 110 12
2LEM 020 100 S06 1.5 20 60 6 2LEM 120 500 S12 12 40 100 12
2LEM 020 150 S06 2 6 60 6 2LEM 120 550 S12 12 45 100 12
2LEM 020 200 S06 2 10 60 6 2LEM 120 600 S12 12 50 100 12
2LEM 030 120 S06 2 15 60 6 2LEM 120 700 S12 12 55 110 12
2LEM 030 150 S06 2 20 60 6 2LEM 120 800 S12 12 60 110 12
2LEM 030 200 S06 3 12 70 6 2LEM 140 500 S14 12 70 130 12
2LEM 030 250 S06 3 15 70 6 2LEM 160 400 160 12 80 130 12
2LEM 030 300 S06 3 20 70 6 2LEM 160 550 S16 14 50 110 14
2LEM 040 150 S06 3 25 70 6 2LEM 160 700 S16 16 40 160 16
2LEM 040 200 S06 3 30 70 6 2LEM 160 800 S16 16 55 120 16
2LEM 040 300 S06 4 15 70 6 2LEM 160 1000 S16 16 70 130 16
2LEM 040 350 S06 4 20 70 6 2LEM 200 500 160 16 80 160 16
2LEM 040 400 S06 4 30 75 6 2LEM 200 600 S20 16 100 160 16
2LEM 050 200 S06 4 35 75 6 2LEM 200 1000 S20 20 50 160 20
2LEM 050 250 S06 4 40 80 6 2LEM 250 750 S25 20 60 130 20
2LEM 050 300 S06 5 20 80 6 20 100 200 20
2LEM 050 400 S06 5 25 70 6 25 75 160 25
2LEM 060 200 S06 5 30 75 6
2LEM 060 200 100 5 40 80 6
2LEM 060 250 S06 6 20 75 6
2LEM 060 300 S06 6 20 100 6
2LEM 060 350 S06 6 25 75 6
2LEM 060 400 S06 6 30 80 6
New 2LEM 060 450 S06 6 35 80 6
New 2LEM 060 500 S06 6 40 90 6
2LEM 080 250 S08 6 45 90 6
2LEM 080 250 100 6 50 100 6
2LEM 080 300 S08 8 25 75 8
2LEM 080 350 S08 8 25 100 8
2LEM 080 400 S08 8 30 80 8
2LEM 080 450 S08 8 35 80 8
2LEM 080 500 S08 8 40 90 8
2LEM 080 550 S08 8 45 100 8
New 2LEM 080 600 S08 8 50 100 8
2LEM 100 300 S10 8 55 100 8
2LEM 100 300 110 8 60 110 8
10 30 80 10
10 30 110 10
