MIRAEPO NC TOTAL TOOLING SYSTEM

▣ Morse Taper Holder/Morse Taper Adaptor/Morse Taper Sleeve

Morse Taper Holder (모오스 테이퍼 홀더) MT NO. G1

∅C

L1

규격 MT NO. L1 C G1 가격
BT50-MTB1-45 1 45 25 M6 151,200
BT50-MTB2-45 2 32 M10 154,200
BT50-MTB3-60 3 60 40 M12 158,800
BT50-MTB4-75 4 75 50 M16 166,300

Morse Taper Adaptor (모오스 테이퍼 어댑터)

규격 MT NO D1 C1 H1 가격

MIN MAX

DSA26-MT1 1 26 39 12 35 61,800
DSA26-MT2 2 61,800

MT NO DSA35-MT1 1 35 48 12 35 68,700
DSA35-MT2 2 68,700

∅D1 ∅D1 ∅C1 DSA35-MT3 3 68,700
DSA48-MT2 2 75,600

DSA48-MT3 3 48 67 12 46 75,600
DSA48-MT4 4 82,500
조절NUT H1

Morse Taper Sleeve (모오스 테이퍼 슬리브)

H1 H2 MT NO (B)

L2 MT NO(A) L1
L

규격 MT NO.(A) MT NO.(B) L L1 L2 H1 H2 가격
SCF1-MT2 2 65,300
SCF1-MT3 92 75 17 18 18 67,100
SCF1-MT4 13 72,600
SCF2-MT3 4 100 94 6 20 23 67,100
SCF2-MT4 3 20 20 72,600
SCF3-MT4 124 117.5 6.5 20 29 72,600
2
4 112 94 18

34 124 117.5 6.5

136 117.5 18.5

- 120 -
