MIRAEPO NC TOTAL TOOLING SYSTEM

▣ Face Mill Arbor (NT-FMA)

규격 Fig D1 L1 C1 C2 H1 W1 K1 C4 Mounting 가격
Screw

NT50-FMA25.4-30 30 - 104,300

NT50-FMA25.4-75 75 168,700

NT50-FMA25.4-90 25.4 90 52 63 22 9.3 5 33 MBA-M12 172,400
NT50-FMA25.4-105
105 183,300

NT50-FMA25.4-150 150 206,900

NT50-FMA31.75-30 30 - 110,400

NT50-FMA31.75-75 75 174,200

NT50-FMA31.75-105 105 188,700

NT50-FMA31.75-150 150 223,200

NT50-FMA31.75-200 31.75 200 70 78 30 12.5 7 40 MBA-M16 272,200
NT50-FMA31.75-250 317,600
250

NT50-FMA31.75-300 300 363,000

NT50-FMA31.75-350 350 408,300

NT50-FMA31.75-400 400 453,700

NT50-FMA38.1-30 30 - 113,400
176,000
NT50-FMA38.1-75 1 75

NT50-FMA38.1-105 105 190,500

NT50-FMA38.1-150 150 226,800

NT50-FMA38.1-200 38.1 200 85 34 15.7 9 50 MBA-M20 281,300

NT50-FMA38.1-250 250 90 326,700

NT50-FMA38.1-300 300 372,000

NT50-FMA38.1-350 350 413,800

NT50-FMA38.1-400 400 462,800

NT50-FMA50.8-30 30 117,900

NT50-FMA50.8-75 75 177,800

NT50-FMA50.8-105 105 192,300

NT50-FMA50.8-150 50.8 150 229,400
NT50-FMA50.8-200 98 - 36 18.9 10 65 MBA-M24
200 284,600

NT50-FMA50.8-250 250 331,100

NT50-FMA50.8-300 300 376,000

NT50-FMA50.8-350 350 418,200

NT50-FMA47.625-45 45 181,500

NT50-FMA47.625-75 75 254,100

NT50-FMA47.625-105 105 128 - 38 25 12.5 - M16x2 317,600
NT50-FMA47.625-150 2 47.625 150 S.H.C.S 408,300
NT50-FMA47.625-200 499,100
200

NT50-FMA47.625-250 250 589,800

NT50-FMA47.625-300 300 680,600

-5-
