MIRAEPO NC TOTAL TOOLING SYSTEM

▣ Large Connection Adaptor (대경용 연결 어댑터)

Body (바디)

4-M16 L

W1 P·C·D ∅d1 ∅60 ∅D P·C·D

Centering BODY부 4-M16C/B
Plug

규격 d1 D W1 L Body Centering 가격
FD60-FMA47.625-150 P·C·D

Plug

150 FD60-EBD60-150 433,100

FD60-FMA47.625-200 200 FD60-EBD60-200 501,800

FD60-FMA47.625-250 250 FD60-EBD60-250 577,500

FD60-FMA47.625-300 300 FD60-EBD60-300 660,000

FD60-FMA47.625-350 47.625 128.5 25 350 FD60-EBD60-350 CB60*47.625 101.6 742,500

FD60-FMA47.625-400 400 FD60-EBD60-400 825,000

FD60-FMA47.625-450 450 FD60-EBD60-450 921,200

FD60-FMA47.625-500 500 FD60-EBD60-500 1,017,500

FD60-FMA47.625-550 550 FD60-EBD60-550 1,113,700

FD60-FMB60-150 150 FD60-EBD60-150 433,100

FD60-FMB60-200 200 FD60-EBD60-200 501,800

FD60-FMB60-250 250 FD60-EBD60-250 577,500

FD60-FMB60-300 300 FD60-EBD60-300 660,000

FD60-FMB60-350 60 128.5 25 350 FD60-EBD60-350 CB60*60 101.6 742,500

FD60-FMB60-400 400 FD60-EBD60-400 825,000

FD60-FMB60-450 450 FD60-EBD60-450 921,200

FD60-FMB60-500 500 FD60-EBD60-500 1,017,500

FD60-FMB60-550 550 FD60-EBD60-550 1,113,700

Centering Plug (센터링 플러그)

H1

규격 C d1 H1 가격

CB60*47.625 47.625 36 34,300

∅C ∅d1 60

CB60*60 60 23 34,300

- 특 징-
∙Long Facing 작업 할 때 강력하고 떨림을 최대한 보정함.
∙다기능 대경용 보링헤드를 장착하여 황ㆍ정삭 보링이 용이함.
