MIRAEPO NC TOTAL TOOLING SYSTEM

▣ Square Tool Boring Bar (MT-BSB)

                                               H1                 MT NO.
                                                   G1
                                    ∅D ∅C1
                                                             ∅C2

                                                    □ W1
                                               15 L1

규격                   D              H1 C1 C2 G1 W1        Boring Bite(별도)        가격
                                L1                            규격 길이
                                                                                199,600
                Min Max                                                         217,800
                                                                                235,900
MT5T-BSB25-120 25 52 120 50 20 22 M8 8 TCBS-08 BS-108 22,35                     272,200
                                                                                308,500
MT5T-BSB38-165 38 70 165 70 30 33                   10 TCBS-10 BS-110 34,50     326,700
                                                                                363,000
MT5T-BSB50-165          165                                                     417,400
                                                                                435,600
                50 90               85 40 44        13 TCBS-13 BS-113 45,60     453,700
                                                                                235,900
MT5T-BSB50-210          210                                                     254,100
                                                                                272,200
MT5T-BSB62-165          165                       M10                           290,400
                                    50 16 TCBS-16 BS-116 56,80                  308,500
                62 115                                                          344,800
                                                                                381,100
MT5T-BSB62-225          225                                                     453,700
                                                                                490,000
MT5T-BSB72-165          165                                                     562,600

                72 135              - 60 -          19                  66,95

MT5T-BSB72-225          225

                                                        TCBS-19 BS-119

MT5T-BSB90-165          165

                90 150              75 M12 19                           82,110

MT5T-BSB90-210          210

MT6T-BSB25-120 25 52 120 50 20 22 M8 8 TCBS-08 BS-108 22,35

MT6T-BSB38-165 38 70 165 70 30 33                   10 TCBS-10 BS-110 34,50

MT6T-BSB50-165  50 90   165         85 40 44        13 TCBS-13 BS-113 45,60

MT6T-BSB50-225          225

MT6T-BSB62-180          180                    M10

MT6T-BSB62-255  62 115  255         95 50 56        16 TCBS-16 BS-116 56,80

MT6T-BSB72-195  72 135  195         110 60 63                           66,95

MT6T-BSB72-285          285

MT6T-BSB90-210          210                         19 TCBS-19 BS-119

MT6T-BSB90-300  90 150  300         - 75 - M12                          82,110
