Φd a˚ CNC HIGH SPEED LIVE CENTERS
ΦD
L1
L
Dimension Φd a˚ L Unit : mm
14 1˚25'50" 64
Morse Taper(MT) ΦD(Gauge line) 19 1˚26'16" 79 L1
2 Φ17.780 25 1˚29'15" 100
3 Φ23.825 35 1˚30'26" 128 4
4 Φ31.267 51 1˚29'36" 179 7
5 Φ44.399 65 1˚29'22" 248 9
6 Φ63.348 9
7 Φ83.058 12
12
Special Type
POINTTECH offer the special shape of live or dead-center internationally POINT TECH CO.,LTD
Head company's technical design team will promptly contact with end-user.
And we offer you the drawing includes customer's requirements
POINTTECH's special model guarantee Quality, Fast delivery, Reasonable price.
Feel free to contact by e-mail 'point@pointtec.com'
