Page 194 - SSK

Hydraulic
Chuck

Shrink Fit EXTENSION BAR (For FINE & TWIN BORING BAR - SMALL BORE) BAH
Holder

Milling D
Chuck d
Boring Dia.
SK Slim Boring Dia. L
Chuck
Unit : mm
ER Collet MODEL No. dD L 중량(Kg)
Chuck E-BAH1-20 11 19 20
E-BAH1-30 11 19 30 FBH
N&COHDtorhilldel reCTrhsouoclk E-BAH2-30 14 24 30
E-BAH2-45 14 24 45 L2 L3
Arbor Morse Taper E-BAH3-30 18 31 30
E-BAH3-45 18 31 45
Tapping ChuckSynchro E-BAH4-45 22 39 45
E-BAH4-60 22 39 60
E-BAH5-60 28 50 60
E-BAH5-90 28 50 90
E-BAH6-60 36 64 60
E-BAH6-100 36 64 100
E-BAH7-105 46 90 105

Tapping ER FINE BORING HEAD (SMALLBORE)
Chuck

Tapping L
Chuck

Side Lock Arbor
& End Mill Holder

L1

Face Mill Unit : mm
Arbor
FRONT BORE BACK BORE
MODEL No. CARTRIDGE L1 BORE RANGE L2 L3 INSERT 중량(Kg)
BORE RANGE L
FBH20
Shell Mill FBH25 FBH1-1 20~26 32.5 29.5 - 10.5 19 TP08
Arbor FBH32
FBH41 FBH2-1 25~33 35.5 32.5 - 10.5 19 TP08
FBH53
FBH68 FBH3-1 32~42 40 35 - 10 25 TP08
FBH100
FBH100-2 FBH4-1 41~54 47 43 - 14 29 TP11

194 FBH5-1 53~70 57 53 52~70 19 34 TP11

Boring FBH6-1 68~100 71 67.2 80~100 22 45.2 TP11
System
FBH6-1 100~153 71 67.2 112~153 22 45.2 TP11

FBH6-1 100~153 87 83.2 112~153 38 45.2 TP11

Accessory TOOL CO., LTD. www.ssktool.co.kr
