SK COLLET SKC Shrink Fit
Holder
◇ 강력한 Chucking력의 8' Taper 및 높은 정밀도 보장
◇ 0.9 - 25.4까지 다양한 Size의 공구에 사용 가능 Milling
◇ E/M, DRILL, TAP, REAMER 등 다양한 공구에 적용 가능 Chuck

SK Slim
Chuck

* 일반급 - 5㎛ 이내 ER Collet
* P 급 - 3㎛ 이내 Chuck

TYPE MODEL No. CLAMPING TYPE MODEL No. CLAMPING TYPE MODEL No. Unit : mm N&COHDtroilhlledreCrThsouoclk
SKC16 RANGE (d) SKC20 RANGE (d) SKC25 CLAMPING
SKC16-3 2.75 ~ 3.0 SKC20-4 SKC25-16.5 RANGE (d) Morse TaperArbor
SKC16-3.5 SKC20-4.5 3.5 ~ 4.0 SKC25-17 16.0 ~ 16.5
SKC16-4 3.0 ~ 3.5 SKC20-5 4.0 ~ 4.5 SKC25-17.5 16.5 ~ 17.0 Synchro Tapping Chuck
SKC16-4.5 3.5 ~ 4.0 SKC20-5.5 4.5 ~ 5.0 SKC25-18 17.0 ~ 17.5
SKC16-5 4.0 ~ 4.5 SKC20-6 5.0 ~ 5.5 SKC25-18.5 17.5 ~ 18.0 Tapping ER
SKC16-5.5 4.5 ~ 5.0 SKC20-6.5 5.5 ~ 6.0 SKC25-19 18.0 ~ 18.5 Chuck
SKC16-6 5.0 ~ 5.5 SKC20-7 6.0 ~ 6.5 SKC25-19.5 18.5 ~ 19.0
SKC16-6.5 5.5 ~ 6.0 SKC20-7.5 6.5 ~ 7.0 SKC25-20 19.0 ~ 19.5 Tapping
SKC16-7 6.0 ~ 6.5 SKC20-8 7.0 ~ 7.5 SKC25-20.5 19.5 ~ 20.0 Chuck
SKC16-7.5 6.5 ~ 7.0 SKC20-8.5 7.5 ~ 8.0 SKC25-21 20.0 ~ 20.5
SKC16-8 7.0 ~ 7.5 SKC20-9 8.0 ~ 8.5 SKC25-21.5 20.5 ~ 21.0 Side Lock Arbor
SKC16-8.5 7.5 ~ 8.0 SKC20-9.5 8.5 ~ 9.0 SKC25-22 21.0 ~ 21.5 & End Mill Holder
SKC16-9 8.0 ~ 8.5 SKC20-10 9.0 ~ 9.5 SKC25-22.5 21.5 ~ 22.0
SKC16-9.5 8.5 ~ 9.0 SKC20-10.5 9.5 ~ 10.0 SKC25-23 22.0 ~ 22.5
SKC16-10 9.0 ~ 9.5 SKC20-11 10.0 ~ 10.5 SKC25-23.5 22.5 ~ 23.0
SKC16-10.5 9.5 ~ 10.0 SKC20-11.5 10.5 ~ 11.0 SKC25-24 23.0 ~ 23.5
SKC16-11 10.0 ~ 10.5 SKC20-12 11.0 ~ 11.5 SKC25-24.5 23.5 ~ 24.0
SKC16-11.5 10.5 ~ 11.0 SKC20-12.5 11.5 ~ 12.0 SKC25-25 24.0 ~ 24.5
SKC16-12 10.0 ~ 11.5 SKC20-13 12.0 ~ 12.5 SKC25-25.4 24.5 ~ 25.0
SKC16-12.5 11.5 ~ 12.0 SKC20-13.5 12.5 ~ 13.0 25.0 ~ 25.4
SKC16-13 12.0 ~ 12.5 SKC20-14 13.0 ~ 13.5
SKC16-13.5 12.5 ~ 13.0 SKC20-14.5 13.5 ~ 14.0 Face Mill
SKC16-14 13.0 ~ 13.5 SKC20-15 14.0 ~ 14.5 Arbor
SKC16-14.5 13.5 ~ 14.0 SKC20-15.5 14.5 ~ 15.0
SKC16-15 14.0 ~ 14.5 SKC20-16 15.0 ~ 15.5
SKC16-15.5 14.5 ~ 15.0 SKC20-16.5 15.5 ~ 16.0
SKC16-16 15.0 ~ 15.5 SKC20-17 16.0 ~ 16.5
15.5 ~ 16.0 SKC20-17.5 16.5 ~ 17.0
SKC20-18 17.0 ~ 17.5
SKC20-18.5 17.5 ~ 18.0 Shell Mill
SKC20-19 18.0 ~ 18.5 Arbor
SKC20-19.5 18.5 ~ 19.0
▶ 재고 관리 제품 SKC20-20.0 19.0 ~ 19.5
19.5 ~ 20.0

Boring
System

TOOL CO., LTD. www.ssktool.co.kr 087 Accessory
