초경 탭(JIS규격)잍
TTAAPPSS

2P/4P 롤탭

ROLL TAPS

- 막힌 구멍 및 관통구멍 가공용으로써 비철금속
가공에 적합

초경탭(JIS규격)시리즈 M3~M6 KI I
KK L 2P/4P

Ød

KI I
L

M8~M24

WROM...series CARBIDE 비코팅

EDP. No. 호칭치수 등급 L l d K Kl 오일홈수
M3 X 0.5 GH5
2P 4P M4 X 0.7 GH6
M5 X 0.8 GH6
WROM0305020S - M6 X 1.0 GH7 46 11 4 3.2 6 1
M8 X 1.25 GH7 4
WROM0305020M WROM0305040M M10 X 1.25 GH7 1
M10 X 1.50 GH7 4
WROM0407020S - M12 X 1.0 GH7 52 13 5 4 7 1
M12 X 1.25 GH7 4
WROM0407020M WROM0407040M M12 X 1.5 GH7 1
M12 X 1.75 GH8 4
WROM0508020S - 60 16 5.5 4.5 7 1
4
WROM0508020M WROM0508040M 1
4
WROM0610020S - 62 19 6 4.5 7 1
4
WROM0610020M WROM0610040M 1
4
WROM0812520S - 70 22 6.2 5 8 1
4
WROM0812520M WROM0812540M 1
4
WROM1012520S - 75 24 7 5.5 8 1
4
WROM1012520M WROM1012540M

WROM1015020S - 75 24 7 5.5 8

WROM1015020M WROM1015040M

WROM1210020S - 82 29 8.5 6.5 9

WROM1210020M WROM1210040M

WROM1212520S - 82 29 8.5 6.5 9

WROM1212520M WROM1212540M

WROM1215020S - 82 29 8.5 6.5 9

WROM1215020M WROM1215040M

WROM1217520S - 82 29 8.5 6.5 9

WROM1217520M WROM1217540M

■적용 피삭재 ○적합 ◎ 매우적합
