CUTTER SERIES5
ENDMILL CUTTER

▶ ENCC

- STRIGHT SHANK TYPE INSERT TYPE → TAEGU-TEC, WIDIN

Part No. 치수(Dimensions)mm I
Dd L 110
160
ENCC-2517150 25 25 150 110
160
ENCC-2517200 25 25 200 110
160
ENCC-2617150 26 25 150 210
110
ENCC-2617200 26 25 200 160
210
ENCC-3217150 32 32 150 110 2 ST4084-60
160 M4
ENCC-3217200 32 32 200 210
110
ENCC-3217250 32 32 250 160
210
ENCC-3317150 33 32 150 110
160
ENCC-3317200 33 32 200 210

ENCC-3317250 33 32 250 APKT 1705 TX-15
3
ENCC-4017150 40 32 150

ENCC-4017200 40 32 200

ENCC-4017250 40 32 250

ENCC-5017150 50 32 150 ST4101-60W
M4
ENCC-5017200 50 32 200
4
ENCC-5017250 50 32 250

ENCC-5017150-L 50 42 150

ENCC-5017200-L 50 42 200

ENCC-5017250-L 50 42 250

- BORE MOUNTED TYPE INSERT TYPE → TAEGU-TEC, WIDIN

커터 시리즈 Part No. 치수(Dimensions)mm 3
Dd L 4
ESCC-501722 50 22 50 7 APKT 1705 ST4101-60W M4 TX-15
ESCC-631722
ESCC-801727 63 22 50
80 27 50

680
