PLUNGE CUTTER 5

▶ 찍기 커터 / Plunge Cutter CUTTER SERIES

d
W1

L1

- BORE MOUNTED TYPE D

INSERT TYPE → WIDIN

Part No. 치수(Dimensions)mm Θ
D L1 d W1 1˚
1˚
PPMF-050-22R 50 65 22 10.4 1˚ 4 TPEN-130302-P
TPEN-130302-CBN
PPMF-063-22R 63 65 22 10.4 6 PPMA-013A

PPMF-080-27R 80 55 27 12.4 8

R10 BT50

B G M
D1 D K

L1 L

- ARBOR 치수(Dimensions)mm

Part No. D D1 L L1 W B M
22
BT50-PPMT-5022100 100
BT50-PPMT-5022150
BT50-PPMT-5022200 150
BT50-PPMT-5022250
BT50-PPMT-5022300 200
BT50-PPMT-5022350
BT50-PPMT-5022400 47 250
BT50-PPMT-6322100
BT50-PPMT-6322150 300
BT50-PPMT-6322200
BT50-PPMT-6322250 350
BT50-PPMT-6322300
BT50-PPMT-6322350 400
BT50-PPMT-6322400
BT50-PPMT-6322450 100 커터 시리즈
BT50-PPMT-6322500
BT50-PPMT-6322550 150 18 10 M10 M24

200

250

60 300
350

400

450

500

500
