SHRINK FIT CHUCK 5

▶ 열박음 척 / Shrink Fit Chuck CUTTER SERIES

Fig 1

Fig 2

- STRIGHT SHANK TYPE

Part No. D D1 d α。 L L1 I II Fig

SL20-D06x185L 20 6 12 20 77 108
SL20-D08x185L
SL20-D10x185L 20 8 14 25 58 127
SL25-D12x185L
SL32-D16x185L 20 10 16 30 38 147
SC20-D06x185L
SC20-D08x185L 25 12 18 30 67 118
SC20-D10x185L
SC25-D12x185L 32 16 25 185 40 100 85 1
SC32-D16x185L 20 6 9.5 20 86 99
ML32-D06x90S
ML32-D08x90S 20 8 11.5 25 70 115
ML32-D10x90S
ML32-D12x90S 20 10 13.5 30 55 130
ML32-D16x90S
MC32-D06x55S 25 12 15.5 30 80 105
MC32-D08x55S
MC32-D10x55S 32 16 19.5 40 103 82
MC32-D12x55S
MC32-D16x55S 32 6 12 20 90 60
MC32-D06x45S
MC32-D08x45S 32 8 14 25 90 60
MC32-D10x45S
MC32-D12x45S 32 10 16 3。30″ 150 30 90 60
MC32-D16x45S
32 12 18 30 90 60

32 16 22 40 90 60

32 6 12 20 55 60

32 8 14 25 55 60

32 10 16 115 30 55 60 2

32 12 18 30 55 60

32 16 22 40 55 60

32 6 12 20 45 60

32 8 14 25 45 60 커터 시리즈

32 10 16 105 30 45 60

32 12 18 30 45 60

32 16 22 40 45 60
