CUTTER SERIES5
FINISH CUTTER

▶ M.S. 커터 / M.S. Cutter

d
a

b

h
H

- BORE MOUNTED TYPE D

INSERT TYPE → WIDIN

Part No. D d 치수(Dimensions)mm a h
100 31.75 L 12.7 32 2
MSFR-100 125 38.1 15.9 38 2
MSFR-125 160 50.8 65 19.0 38 4
MSFR-160 200 47.625 25.4 38 4
MSFR-200

▶ M.S. Cutter 부품 / M.S. Cutter Part

Part No. 치수(Dimensions)mm
규격
1(로케이트) 2(조정왯지) 3(조정왯지스크류) 4(로케이트고정스크류) 5(인써트스크류) 6(고급볼트)
MSFR-1 MSFR-2 ST511-43 M5 SCM-M5×5
MSFR-3 SCM-M5×15

▶ M.S. Cutter 사용 인서트 / M.S. Cutter Insert

R

커터 시리즈 Q°

Part No. d d t
SPHA435FNW 12.7
치수(Dimensions)mm INSERT TYPE → TUNGALOY
tR
4.76 2.0 Θ
11˚

750
