cBN Series

cBN 멀티코너 타입(네가티브/포지티브)

※ T-2NU-□□□□△△△△△△형번은 포장단위 10ea 입니다.  재종

                   형상 형번
                      DNC250
                           DNC350
                                DNC400
                                      DB1000
                                           DB2000
                                                DBN250
                                                      DBN300
                                                           DBN400
                                                                DBN700A
                                                                      DBNX20
                                                                            S (인선길이)
                                                                                  IC (내접원)
                                                                                         T (두께)
                                                                                               R (노즈R)
                                                                                                      ØD (홀지름)
                                                                                                            g
                                                                                                                   포장단위

D   T-2NU-CNGA120404  ●- - - - - -        ---  2.6 12.7 4.76 0.4 5.16      10
    2NU-CNGA120404    ●● - ●● - -         -●-  2.7 12.7 4.76 0.4 5.16 9.9  1
    2NU-CNGA120404F   ●- - - - - -        ---  2.7 12.7 4.76 0.4 5.16 9.9  1
    2NU-CNGA120404T   ●- -●- - -          ---  2.7 12.7 4.76 0.4 5.16 9.9  1
    2NU-CNGA120404W   ●- - - - - -        ---  2.7 12.7 4.76 0.4 5.16 9.9  1
    2NU-CNGA120404WF  ●- - - - - -        ---  2.7 12.7 4.76 0.4 5.16 9.9  1
    2NU-CNGA120408    ●● - ●● - -         -●-  2.6 12.7 4.76 0.8 5.16 9.9  1
    T-2NU-CNGA120408  ●● - - - - -        ---  2.6 12.7 4.76 0.8 5.16 9.9  10
    2NU-CNGA120408F   ●- - - - - -        ---  2.6 12.7 4.76 0.8 5.16 9.9  1
    2NU-CNGA120408T   ●- -●- - -          ---  2.6 12.7 4.76 0.8 5.16 9.9  1
    2NU-CNGA120408W   ●● - ● - - -        -●-  2.6 12.7 4.76 0.8 5.16 9.9  1
    2NU-CNGA120408WF  - - - -●- -         ---  2.6 12.7 4.76 0.8 5.16 9.9  1
    2NU-CNGA120412    ●● - - - - -        ---  2.6 12.7 4.76 1.2 5.16 9.9  1
    2NU-CNGA120412F   ●- - - - - -        ---  2.6 12.7 4.76 1.2 5.16 9.9  1
    2NU-CNGA120412T   ●- - - - - -        ---  2.6 12.7 4.76 1.2 5.16 9.9  1
    2NU-CNGA120412W   ● - - ●● - -        -●-  2.6 12.7 4.76 1.2 5.16 9.9  1
    2NU-CNGA120412WF  ●- - - - - -        ---  2.6 12.7 4.76 1.2 5.16 9.9  1
    2NU-CNGA120412WT  - - -●- - -         ---  2.6 12.7 4.76 1.2 5.16 9.9  1
    2NU-CNMA120404    - - - - -●-         ---  2.7 12.7 4.76 0.4 5.16 9.9  1
    2NU-CNMA120408    - - - - -●-         ---  2.7 12.7 4.76 0.4 5.16 9.9  1

DD  2NS-CNGA120408    - - ● - - - - ● - - 2.6 12.7 4.76 1.2 5.16 9.9 1

    2NU-DNGA150404    ●● - ●●● - -        - 2.6 12.7 4.76 0.4 5.16 12.3 1
    2NU-DNGA150404F
    2NU-DNGA150404T   ●- - -          - - - - - 2.6 12.7 4.76 0.4 5.16 12.3 1
    2NU-DNGA150408
    2NU-DNGA150408F   ●- -            - - - - - 2.6 12.7 4.76 0.4 5.16 12.3 1
    2NU-DNGA150408T
    2NU-DNGA150412    ●● - ●●● - -        - 2.2 12.7 4.76 0.8 5.16 12.3 1
    2NU-DNGA150412F
    2NU-DNGA150412T   ●- - -          - - - - - 2.2 12.7 4.76 0.8 5.16 12.3 1
    2NU-DNMA150608
                      ● - - ● ● - - - - - 2.2 12.7 4.76 0.8 5.16 12.3 1

                      ● ● - - - - - - - - 2.5 12.7 4.76 1.2 5.16 12.3 1

                      ● - - - - - - - - - 2.5 12.7 4.76 1.2 5.16 12.3 1

                      ● - - - - - - - - - 2.5 12.7 4.76 1.2 5.16 12.3 1

                      - - - - - - - - - ● 2.2 12.7 6.35 0.8 5.16 16.2 1

D   2NS-DNGA150408    - - - - - - - ● - - 2.2 12.7 4.76 0.8 5.16 12.3 1

    2NS-VNGA160408    - - ● - - - - ● - - 2.6 9.525 4.76 0.8 3.81 10.2 1
