cBN Series

cBN 멀티코너 타입(네가티브/포지티브)

※ T-2NU-□□□□△△△△△△형번은 포장단위 10ea 입니다. 재종 Feature

형상 형번
DNC250
DNC350
DNC400
DB1000
DB2000
DBN250
DBN300
DBN400
DBN700A
DBNX20
S (인선길이)
IC (내접원)
T (두께)
R (노즈R)
Ød (홀지름)
g
포장단위

3NU-TCGW090204 ● - - - - - - - - - 2.5 5.56 2.38 0.4 2.5 1.6 1 BT shank
3NU-TCGW090204F ● - - - - - - - - - 2.5 5.56 2.38 0.4 2.5 1.6 1
3NU-TCGW090204T ● - - - - - - - - - 2.5 5.56 2.38 0.4 2.5 1.6 1

3NU-TPGW110304 ●● - ●● - - -●- 2.5 6.35 3.18 0.4 3.4 2.3 1
3NU-TPGW110304F - 2.5 6.35 3.18 0.4 3.4 2.3 1
3NU-TPGW110304T ●- - - 2.5 6.35 3.18 0.4 3.4 2.3 1 S,ST shank
3NU-TPGW110308 --- 2.3 6.35 3.18 0.8 3.4 2.3 1
3NU-TPGW110308F ●- - - -●- 2.3 6.35 3.18 0.8 3.4 2.3 1
3NU-TPGW110308T 2.3 6.35 3.18 0.8 3.4 2.3 1
3NU-TPGB110304 ●● - ●● - - -- 2.5 6.35 3.18 0.4 3.4 2.3 1
3NU-TPGB110304T --- 2.5 6.35 3.18 0.4 3.4 2.3 1
3NU-TPGB110308 ●- - --- 2.3 6.35 3.18 0.8 3.4 2.3 1
3NU-TPGB110308F --- 2.3 6.35 3.18 0.8 3.4 2.3 1
3NU-TPGB110308T ●- - -- --- 2.3 6.35 3.18 0.8 3.4 2.3 1
---
●- - - -●- ---

●- - - - - - HSK shank

●- - - -●-

●- - - - - -

●- - - - - -

3NU-TPGN110308 - - - ● ● - - - - - 2.3 6.35 3.18 0.8 - 2.3 1 SK shank
3NU-TPGN160304 ● ● - - - - - - - - 2.5 9.525 3.18 0.4 - 4.8 1
3NU-TPGN160308 ● - - - - - - - - 2.3 9.525 3.18 0.8 - 4.8 1

NT shank

CNMA120404 - - - - - ● - - - - 4.3 12.7 4.76 0.4 5.16 9.9 1 ccBBNN/PPCCDD
CNMA120408 - - - - - ● - - - ● 4.2 12.7 4.76 0.8 5.16 9.9 1
T-CNMA120408 - - - - - ● - - - - 4.2 12.7 4.76 0.8 5.16 9.9 10

DNMG150404 - - - - - ● - - - - 2.6 12.7 4.76 0.4 5.16 12.3 1
DNMG150408 - - - - - ● ● - - - 2.6 12.7 4.76 0.8 5.16 12.3 1
