Carbide Cutters 초경 티 컷터
Carbide Woodruff Keyseat Cutters
T-Cutter
Item no. D No. of Flute Neck Dia d L Remarks
제품코드 규격 날수 목경 샹크경 전장 비고
TC01CA-010 10.0 6 5 10 46
TC01CA-012 Solid
TC01CA-015 12.0 6 8 12
TC01CA-016 54
TC01CA-018 15.0 6 8 12 65
TC01CA-020 65
TC01CA-022 16.0 6 8 12 70
TC01CA-025 70
TC01CA-030 18.0 6 10 16 72
TC01CA-035 78 Tips Blazed
TC01CA-040 20.0 6 12 16 82
TC01CA-045 90
TC01CA-050 22.0 6 12 16 100
105
25.0 6 14 16 110
30.0 8 16 20
35.0 8 16 20
40.0 8 18 20
45.0 10 22 25
50.0 10 22 25
Tolerance (허용공차)
bdL
e8 h8 ±1
152 2014/15 DYC TOOLS LIST
