3 Flutes 45 Helix Coner Radius End Mills for Aluminum

3 45

Endmills for Aluminum, AL alloy, non-ferrous and
non-metallic materials.
Applied fine WC grade for excellent surface finish.
Minimize built up edge by double edge and deep pocket design.
Tetrabond TAC coating provides excellent work surface finish by
high hardness and low friction.
High speed, feed applicable by 3 flute 45 degree helix and short flute design.

0.005 0.01 0.015 D Size D Tolerance
R0.5 R1 ~ 1.5 R2 ~ 5 6 ~ 20 +0 ~ -0.015mm

mm

Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia
Non coated Coated DR L1 Non coated Coated
L2 L d
6 X R0.5 15
3ALC 060 005 050 3ALCC 060 005 050 6 X R0.5 7 - 50 6 FOR ALUMINUM
3ALC 060 005 070 3ALCC 060 005 070 6 X R1 15 20 70 6
3ALC 060 010 050 3ALCC 060 010 050 6 X R1 7 - 50 6
3ALC 060 010 070 3ALCC 060 010 070 8 X R0.5 20 20 70 6
3ALC 080 005 060 3ALCC 080 005 060 8 X R0.5 9 - 60 8
3ALC 080 005 080 3ALCC 080 005 080 8 X R1 20 25 80 8
3ALC 080 010 060 3ALCC 080 010 060 8 X R1 9 - 60 8
3ALC 080 010 080 3ALCC 080 010 080 8 X R2 20 25 80 8
3ALC 080 020 060 3ALCC 080 020 060 8 X R2 9 - 60 8
3ALC 080 020 080 3ALCC 080 020 080 8 X R2.5 9 25 80 8
3ALC 080 025 080 3ALCC 080 025 080 10 X R0.5 25 25 80 8
New 3ALC 100 005 070 New 3ALCC 100 005 070 10 X R0.5 11 - 70 10
New 3ALC 100 005 100 New 3ALCC 100 005 100 10 X R1 25 30 100 10
3ALC 100 010 070 3ALCC 100 010 070 10 X R1 11 - 70 10
3ALC 100 010 100 3ALCC 100 010 100 10 X R1.5 25 30 100 10
3ALC 100 015 070 3ALCC 100 015 070 10 X R1.5 11 - 70 10
3ALC 100 015 100 3ALCC 100 015 100 10 X R2 25 30 100 10
3ALC 100 020 070 3ALCC 100 020 070 10 X R2 11 - 70 10
3ALC 100 020 100 3ALCC 100 020 100 10 X R2.5 11 30 100 10
3ALC 100 025 100 3ALCC 100 025 100 12 X R0.5 30 30 100 10
New 3ALC 120 005 075 New 3ALCC 120 005 075 12 X R0.5 13 - 75 12
New 3ALC 120 005 110 New 3ALCC 120 005 110 12 X R1 30 36 110 12
3ALC 120 010 075 3ALCC 120 010 075 12 X R1 13 - 75 12
3ALC 120 010 110 3ALCC 120 010 110 12 X R1.5 13 36 110 12
3ALC 120 015 110 3ALCC 120 015 110 12 X R2 30 36 110 12
3ALC 120 020 075 3ALCC 120 020 075 12 X R2 13 - 75 12
3ALC 120 020 110 3ALCC 120 020 110 12 X R2.5 13 36 110 12
3ALC 120 025 110 3ALCC 120 025 110 12 X R3 30 36 110 12
3ALC 120 030 075 3ALCC 120 030 075 12 X R3 13 - 75 12
3ALC 120 030 110 3ALCC 120 030 110 12 X R4 30 36 110 12
3ALC 120 040 075 3ALCC 120 040 075 12 X R4 13 - 75 12
3ALC 120 040 110 3ALCC 120 040 110 16 X R0.5 17 36 110 12
New 3ALC 160 005 130 New 3ALCC 160 005 130 16 X R1 35 50 130 16
3ALC 160 010 090 3ALCC 160 010 090 16 X R1 17 - 90 16
3ALC 160 010 130 3ALCC 160 010 130 16 X R2 35 50 130 16
3ALC 160 020 090 3ALCC 160 020 090 16 X R2 17 - 90 16
3ALC 160 020 130 3ALCC 160 020 130 16 X R2.5 17 50 130 16
3ALC 160 025 130 3ALCC 160 025 130 16 X R3 35 50 130 16
3ALC 160 030 090 3ALCC 160 030 090 16 X R3 17 - 90 16
3ALC 160 030 130 3ALCC 160 030 130 16 X R4 35 50 130 16
3ALC 160 040 090 3ALCC 160 040 090 16 X R4 17 - 90 16
3ALC 160 040 130 3ALCC 160 040 130 16 X R5 35 50 130 16
3ALC 160 050 090 3ALCC 160 050 090 20 X R1 21 - 90 16
New 3ALC 200 010 150 New 3ALCC 200 010 150 20 X R2 21 60 150 20
3ALC 200 020 150 3ALCC 200 020 150 20 X R2.5 21 60 150 20
3ALC 200 025 150 3ALCC 200 025 150 20 X R3 21 60 150 20
3ALC 200 030 150 3ALCC 200 030 150 20 X R4 21 60 150 20
3ALC 200 040 150 3ALCC 200 040 150 60 150 20
