4 Flutes Straight Flute Taper End Mills

4

Endmills for various work materials, hardened steel,
pre-hardened steel, tool steel and cast iron.
Good wear resistance by Si-based PVD coating.
Optimum for chamfering with straight 4flutes.
Minimize fracturing at high feed by high TRS fine WC grade.

0.05 0 D Size D Tolerance
0 0 +0 .05~ -0mm

mm

Order Number Diameter Angle Length Overall Shank
of cut Length Dia
4STE 000 600 S03 D
4STE 000 900 S03 L1 L d
4STE 000 600 S04 0
4STE 000 900 S04 0 60 2.5 50 3
4STE 000 600 S06 0 90 1.5 50 3
4STE 000 900 S06 0 60 3.4 50 4
4STE 000 600 S08 0 90 2 50 4
4STE 000 900 S08 0 60 5.1 60 6
4STE 000 600 S10 0 90 3 60 6
4STE 000 900 S10 0 60 6.9 65 8
4STE 000 600 S12 0 90 4 65 8
4STE 000 900 S12 0 60 8.6 75 10
0 90 5 75 10
0 60 10.3 80 12
90 6 80 12

Available Cutting Shape
