2 Flutes Coner C End Mills

2 45

Pre-hardened steel, Cast iron, Non-metallic materials
Multi function endmill for corner chamfering, side wall.
Applied fine WC grade optimized for various non-ferrous
and non-metallic work materials.
JCRO coating provides wear resistance improvement as well as
avoid edge stress in various applications.
Endmills for various work materials.

D Size D Tolerance

1 ~ 5 +0 ~ -0.01mm

0 0.01 0.01 0.025 6 ~ 12 -0.01 ~ -0.025mm

1~ 5 6~ 12 mm

Order Number Diameter Chamfer Length Overall Shank GENERAL PURPOSE
of cut Length Dia
2CCMC 010 0002 S04 D C L1 d
2CCMC 010 0005 S04 L
2CCMC 010 001 S04 1 0.02 2.5 4
2CCMC 010 002 S04 1 0.05 2.5 45 4
2CCMC 010 003 S04 1 0.1 2.5 45 4
2CCMC 015 0005 S04 1 0.2 2.5 45 4
2CCMC 015 001 S04 1 0.3 2.5 45 4
2CCMC 015 002 S04 1.5 0.05 4 45 4
2CCMC 015 003 S04 1.5 0.1 4 45 4
2CCMC 015 005 S04 1.5 0.2 4 45 4
2CCMC 020 0005 S04 1.5 0.3 4 45 4
2CCMC 020 001 S04 1.5 0.5 4 45 4
2CCMC 020 002 S04 2 0.05 6 45 4
2CCMC 020 003 S04 2 0.1 6 45 4
2CCMC 020 004 S04 2 0.2 6 45 4
2CCMC 020 005 S04 2 0.3 6 45 4
2CCMC 030 0005 S06 2 0.4 6 45 4
2CCMC 030 001 S06 2 0.5 6 45 4
2CCMC 030 002 S06 3 0.05 8 45 6
2CCMC 030 003 S06 3 0.1 8 50 6
2CCMC 030 005 S06 3 0.2 8 50 6
2CCMC 030 010 S06 3 0.3 8 50 6
2CCMC 040 0005 S06 3 0.5 8 50 6
2CCMC 040 001 S06 3 8 50 6
2CCMC 040 002 S06 4 1 11 50 6
2CCMC 040 003 S06 4 0.05 11 50 6
2CCMC 040 005 S06 4 0.1 11 50 6
2CCMC 040 010 S06 4 0.2 11 50 6
2CCMC 040 015 S06 4 0.3 11 50 6
2CCMC 050 001 S06 4 0.5 11 50 6
2CCMC 050 002 S06 4 11 50 6
2CCMC 050 005 S06 5 1 13 50 6
2CCMC 050 010 S06 5 1.5 13 60 6
2CCMC 050 015 S06 5 0.1 13 60 6
2CCMC 050 020 S06 5 0.2 13 60 6
2CCMC 060 0005 S06 5 0.5 13 60 6
2CCMC 060 001 S06 5 1 13 60 6
2CCMC 060 002 S06 6 1.5 13 60 6
2CCMC 060 003 S06 6 2 13 60 6
2CCMC 060 005 S06 6 0.05 13 60 6
2CCMC 060 010 S06 6 0.1 13 60 6
2CCMC 060 015 S06 6 0.2 13 60 6
2CCMC 060 020 S06 6 0.3 13 60 6
2CCMC 060 025 S06 6 0.5 13 60 6
2CCMC 080 001 S08 6 1 13 60 6
2CCMC 080 002 S08 6 1.5 13 60 6
2CCMC 080 005 S08 8 2 19 60 8
2CCMC 080 010 S08 8 2.5 19 70 8
8 0.1 19 70 8
8 0.2 19 70 8
0.5 70
1
