3 Flutes Micro Rib Ball End Mills

3

Endmills for Acryl, A.B.S, Aluminum, non-ferrous and
non-metallic materials.
Minimize chattering by short flute design.
Optimum for high speed, feed condition by short flute design.
Reinforced edge design for preventing edge chipping.
Excellent wear resistance by applying fine WC grade.

0.005 0.01 0.015 D Size D Tolerance
0.5 ~ 2R 3 ~ 6R 8R 1~4 +0 ~ -0.01mm
6 ~ 12 -0.005 ~ -0.015mm
16 -0.01 ~ -0.02mm

mm

Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia
3MRB 010 050 S04 RD L1 L2 L d
3MRB 010 100 S04
3MRB 010 150 S04 0.5R X 1 3 5 70 4
3MRB 010 200 S04 0.5R X 1 3 10 70 4
3MRB 010 250 S04 0.5R X 1 3 15 70 4
3MRB 015 100 S04 0.5R X 1 3 20 70 4
3MRB 015 150 S04 0.5R X 1 3 25 70 4
3MRB 015 200 S04 0.75R X 1.5 4.5 10 70 4
3MRB 015 250 S04 0.75R X 1.5 4.5 15 70 4
3MRB 015 300 S04 0.75R X 1.5 4.5 20 70 4
3MRB 020 100 S04 0.75R X 1.5 4.5 25 70 4
3MRB 020 150 S04 0.75R X 1.5 4.5 30 70 4
3MRB 020 200 S04 1R X 2 6 10 70 4
3MRB 020 250 S04 1R X 2 6 15 70 4
3MRB 020 300 S04 1R X 2 6 20 70 4
3MRB 030 200 080 1R X 2 6 25 70 4
3MRB 030 200 S04 1R X 2 6 30 70 4
3MRB 030 300 100 1.5R X 3 15 20 80 3
3MRB 030 300 S04 1.5R X 3 9 20 80 4
3MRB 040 200 080 1.5R X 3 15 30 100 3
3MRB 040 300 100 1.5R X 3 9 30 80 4
3MRB 060 300 100 2R X 4 12 20 80 4
3MRB 060 400 150 2R X 4 12 30 100 4
3MRB 080 400 120 3R X 6 18 30 100 6
3MRB 080 500 150 3R X 6 18 40 150 6
3MRB 100 500 120 4R X 8 24 40 120 8
3MRB 100 600 150 4R X 8 24 50 150 8
3MRB 120 600 150 5R X 10 30 50 120 10
3MRB 160 700 160 5R X 10 30 60 150 10
6R X 12 36 60 150 12
8R X 16 54 70 160 16
