2 Flutes Micro Rib Ball End Mills

2

Endmills for Acryl, A.B.S, Aluminum, non-ferrous and
non-metallic materials.
Minimize chattering by short flute design.
Excellent tool rigidity by short flute design at high speed, feed
machining.
Reinforced edge design for preventing edge chipping.
Excellent wear resistance by applying fine WC grade.

0.005 0.01 D Size D Tolerance
0.1 ~ 2.5R 3R 6~5 +0 ~ -0.01mm
6 -0.005~ -0.015mm

mm

FOR A.B.S Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia of cut Length Length Dia
2MRB 002 005 S04 RD L1 L2 L d 2MRB 014 100 S04 RD L1 L2 L d
2MRB 002 010 S04 2MRB 014 160 S04
2MRB 002 015 S04 0.1R X 0.2 0.3 0.5 40 4 2MRB 015 060 S04 0.7R X 1.4 2.8 10 50 4
2MRB 002 020 S04 0.1R X 0.2 0.3 1 40 4 2MRB 015 100 S04 0.7R X 1.4 2.8 16 50 4
2MRB 003 010 S04 0.1R X 0.2 0.3 1.5 40 4 2MRB 015 140 S04 0.75R X 1.5 3 6 50 4
2MRB 003 020 S04 0.1R X 0.2 0.3 2 40 4 2MRB 015 160 S04 0.75R X 1.5 3 10 50 4
2MRB 003 030 S04 0.15R X 0.3 0.45 1 40 4 2MRB 015 200 S04 0.75R X 1.5 3 14 50 4
2MRB 003 050 S04 0.15R X 0.3 0.45 2 40 4 2MRB 015 250 S04 0.75R X 1.5 3 16 50 4
2MRB 004 020 S04 0.15R X 0.3 0.45 3 40 4 2MRB 015 300 S04 0.75R X 1.5 3 20 60 4
2MRB 004 030 S04 0.15R X 0.3 0.45 5 40 4 2MRB 016 060 S04 0.75R X 1.5 3 25 60 4
2MRB 004 040 S04 0.2R X 0.4 0.6 2 40 4 2MRB 020 080 S04 0.75R X 1.5 3 30 70 4
2MRB 004 050 S04 0.2R X 0.4 0.6 3 40 4 2MRB 020 100 S04 0.8R X 1.6 3.2 6 50 4
2MRB 004 060 S04 0.2R X 0.4 0.6 4 40 4 2MRB 020 120 S04 1R X 2 4 8 50 4
2MRB 005 020 S04 0.2R X 0.4 0.6 5 40 4 2MRB 020 140 S04 1R X 2 4 10 50 4
2MRB 005 040 S04 0.2R X 0.4 0.6 6 40 4 2MRB 020 160 S04 1R X 2 4 12 50 4
2MRB 005 060 S04 0.25R X 0.5 1 2 45 4 2MRB 020 180 S04 1R X 2 4 14 50 4
2MRB 005 080 S04 0.25R X 0.5 1 4 45 4 2MRB 020 200 S04 1R X 2 4 16 50 4
2MRB 005 100 S04 0.25R X 0.5 1 6 45 4 2MRB 020 250 S04 1R X 2 4 18 50 4
2MRB 006 020 S04 0.25R X 0.5 1 8 45 4 2MRB 020 300 S04 1R X 2 4 20 60 4
2MRB 006 040 S04 0.25R X 0.5 1 10 45 4 2MRB 020 350 S04 1R X 2 4 25 60 4
2MRB 006 060 S04 0.3R X 0.6 1.2 2 45 4 2MRB 020 400 S04 1R X 2 4 30 70 4
2MRB 006 080 S04 0.3R X 0.6 1.2 4 45 4 2MRB 025 120 S04 1R X 2 4 35 80 4
2MRB 006 100 S04 0.3R X 0.6 1.2 6 45 4 2MRB 025 200 S04 1R X 2 4 40 80 4
2MRB 007 040 S04 0.3R X 0.6 1.2 8 45 4 2MRB 030 080 S06 1.25R X 2.5 5 12 60 4
2MRB 007 060 S04 0.3R X 0.6 1.2 10 45 4 2MRB 030 120 S06 1.25R X 2.5 5 20 60 4
2MRB 007 080 S04 0.35R X 0.7 1.4 4 45 4 2MRB 030 160 S06 1.5R X 3 6 8 70 6
2MRB 007 100 S04 0.35R X 0.7 1.4 6 45 4 2MRB 030 200 S06 1.5R X 3 6 12 70 6
2MRB 008 040 S04 0.35R X 0.7 1.4 8 45 4 2MRB 030 250 S06 1.5R X 3 6 16 70 6
2MRB 008 060 S04 0.35R X 0.7 1.4 10 45 4 2MRB 030 300 S06 1.5R X 3 6 20 70 6
2MRB 008 080 S04 0.4R X 0.8 1.6 4 45 4 2MRB 030 400 S06 1.5R X 3 6 25 70 6
2MRB 008 100 S04 0.4R X 0.8 1.6 6 45 4 2MRB 030 450 S06 1.5R X 3 6 30 80 6
2MRB 008 120 S04 0.4R X 0.8 1.6 8 45 4 2MRB 040 120 S06 1.5R X 3 6 40 90 6
2MRB 009 060 S04 0.4R X 0.8 1.6 10 45 4 2MRB 040 160 S06 1.5R X 3 6 45 90 6
2MRB 009 100 S04 0.4R X 0.8 1.6 12 45 4 2MRB 040 200 S06 2R X 4 8 12 70 6
2MRB 009 120 S04 0.45R X 0.9 1.8 6 45 4 2MRB 040 250 S06 2R X 4 8 16 70 6
2MRB 010 060 S04 0.45R X 0.9 1.8 10 45 4 2MRB 040 300 S06 2R X 4 8 20 70 6
2MRB 010 080 S04 0.45R X 0.9 1.8 12 45 4 2MRB 040 350 S06 2R X 4 8 25 70 6
2MRB 010 100 S04 0.5R X 1 2 6 50 4 2MRB 040 400 S06 2R X 4 8 30 70 6
2MRB 010 120 S04 0.5R X 1 2 8 50 4 2MRB 040 500 S06 2R X 4 8 35 80 6
2MRB 010 160 S04 0.5R X 1 2 10 50 4 2MRB 050 160 S06 2R X 4 8 40 80 6
2MRB 010 200 S04 0.5R X 1 2 12 50 4 2MRB 050 250 S06 2R X 4 8 50 100 6
2MRB 010 250 S04 0.5R X 1 2 16 50 4 2MRB 050 350 S06 2.5R X 5 10 16 80 6
2MRB 012 060 S04 0.5R X 1 2 20 60 4 2MRB 060 250 S06 2.5R X 5 10 25 80 6
2MRB 012 080 S04 0.5R X 1 2 25 60 4 2MRB 060 350 S06 2.5R X 5 10 35 80 6
2MRB 012 100 S04 0.6R X 1.2 2.4 6 50 4 2MRB 060 500 S06 3R X 6 12 25 80 6
2MRB 012 120 S04 0.6R X 1.2 2.4 8 50 4 2MRB 060 600 S06 3R X 6 12 35 80 6
2MRB 012 160 S04 0.6R X 1.2 2.4 10 50 4 3R X 6 12 50 120 6
2MRB 014 060 S04 0.6R X 1.2 2.4 12 50 4 3R X 6 12 60 120 6
0.6R X 1.2 2.4 16 50 4
0.7R X 1.4 2.8 6 50 4
