4 Flutes JJ Corner Radius End Mills for Hardened Steels

                                    4

JJ series

                                                                           Endmills for pre-hardened and hardened steel (HRc52~70)
                                                                           Good wear resistance by high quality Si-based PVD coating.
                                                                           High precise edge tolerance.
                                                                           Designed for minimizing edge chipping by corner R shape.
                                                                           Various corner R and overall length for wide range application.
                                                                           Outstanding performance at high speed machining by ultra fine
                                                                           (0.2 ) WC grade.

                                    0.005         0.01              0.015                                         D Size       D Tolerance
                                                                   R2 ~ 3                                         0.5 ~ 5  +0 ~ -0.01mm
                                                                                                                  6 ~ 16   -0.005 ~ -0.015mm

                                    R0.05 ~ 0.5 R1 ~ 1.5                                                                                  mm

                     Order Number       Diameter  Length  Overall  Shank            Order Number        Diameter  Length  Overall  Shank
                                                  of cut  Length    Dia                                           of cut  Length    Dia
           New 4JJC 005 0005 S04         DR         L1               d           4JJC 045 005 S06        DR         L1               d
           New 4JJC 005 001 S04                             L                    4JJC 050 001 S06                           L
           New 4JJC 006 0005 S04    0.5 X R0.05     1               4            4JJC 050 002 S06   4.5 X R0.5     11               6
           New 4JJC 006 001 S04     0.5 X R0.1      1      45       4            4JJC 050 003 S06   5 X R0.1       13      75       6
           New 4JJC 007 0005 S04    0.6 X R0.05   1.2      45       4            4JJC 050 005 S06   5 X R0.2       13      75       6
           New 4JJC 007 001 S04     0.6 X R0.1    1.2      45       4            4JJC 050 010 S06   5 X R0.3       13      75       6
           New 4JJC 008 0005 S04    0.7 X R0.05   1.4      45       4            4JJC 060 0005 055  5 X R0.5       13      75       6
           New 4JJC 008 001 S04     0.7 X R0.1    1.4      45       4            4JJC 060 0005 080  5 X R1         13      75       6
           New 4JJC 009 0005 S04    0.8 X R0.05   1.6      45       4            4JJC 060 001 055   6 X R0.05      11      75       6
           New 4JJC 009 001 S04     0.8 X R0.1    1.6      45       4            4JJC 060 001 080   6 X R0.05      13      55       6
                                    0.9 X R0.05   1.8      45       4            4JJC 060 002 055   6 X R0.1       11      80       6
                 4JJC 010 0005 S04  0.9 X R0.1    1.8      45       4            4JJC 060 002 080   6 X R0.1       13      55       6
                 4JJC 010 001 S04   1 X R0.05     2.5      45       4      New 4JJC 060 002 100     6 X R0.2       11      80       6
                 4JJC 010 002 S04   1 X R0.1      2.5      45       4      New 4JJC 060 002 120     6 X R0.2       13      55       6
                 4JJC 010 003 S04   1 X R0.2      2.5      45       4            4JJC 060 003 055   6 X R0.2       13      80       6
                 4JJC 015 0005 S04  1 X R0.3      2.5      45       4            4JJC 060 003 080   6 X R0.2       13     100       6
                 4JJC 015 001 S04   1.5 X R0.05     4      45       4      New 4JJC 060 003 100     6 X R0.3       11     120       6
                 4JJC 015 002 S04   1.5 X R0.1      4      45       4      New 4JJC 060 003 120     6 X R0.3       13      55       6
                 4JJC 015 003 S04   1.5 X R0.2      4      45       4            4JJC 060 005 055   6 X R0.3       13      80       6
                 4JJC 015 005 S04   1.5 X R0.3      4      45       4            4JJC 060 005 080   6 X R0.3       13     100       6
                 4JJC 020 0005 S04  1.5 X R0.5      4      45       4      New 4JJC 060 005 100     6 X R0.5       11     120       6
                 4JJC 020 001 S04   2 X R0.05       6      45       4      New 4JJC 060 005 120     6 X R0.5       13      55       6
                 4JJC 020 002 S04   2 X R0.1        6      45       4            4JJC 060 010 055   6 X R0.5       13      80       6
                 4JJC 020 003 S04   2 X R0.2        6      45       4            4JJC 060 010 080   6 X R0.5       13     100       6
                 4JJC 020 005 S04   2 X R0.3        6      45       4      New 4JJC 060 010 100     6 X R1         11     120       6
                 4JJC 025 001 S04   2 X R0.5        6      45       4      New 4JJC 060 010 120     6 X R1         13      55       6
                 4JJC 025 002 S04   2.5 X R0.1      6      45       4            4JJC 060 015 055   6 X R1         13      80       6
                 4JJC 025 003 S04   2.5 X R0.2      6      50       4            4JJC 060 015 080   6 X R1         13     100       6
                 4JJC 025 005 S04   2.5 X R0.3      6      50       4            4JJC 060 020 055   6 X R1.5       11     120       6
                 4JJC 030 001 S06   2.5 X R0.5      6      50       4            4JJC 060 020 080   6 X R1.5       13      55       6
                 4JJC 030 002 S06   3 X R0.1        8      50       6      New 4JJC 080 002 060     6 X R2         11      80       6
                 4JJC 030 003 S06   3 X R0.2        8      60       6      New 4JJC 080 002 090     6 X R2         13      55       6
                 4JJC 030 005 S06   3 X R0.3        8      60       6            4JJC 080 003 060   8 X R0.2       16      80       8
                 4JJC 030 010 S06   3 X R0.5        8      60       6            4JJC 080 003 090   8 X R0.2       19      60       8
                 4JJC 035 001 S06   3 X R1          8      60       6            4JJC 080 005 060   8 X R0.3       16      90       8
                 4JJC 035 002 S06   3.5 X R0.1      9      60       6            4JJC 080 005 090   8 X R0.3       19      60       8
                 4JJC 035 003 S06   3.5 X R0.2      9      70       6      New 4JJC 080 005 110     8 X R0.5       16      90       8
                 4JJC 035 005 S06   3.5 X R0.3      9      70       6      New 4JJC 080 005 150     8 X R0.5       19      60       8
                 4JJC 040 001 S04   3.5 X R0.5      9      70       6            4JJC 080 010 060   8 X R0.5       19      90       8
                 4JJC 040 001 S06   4 X R0.1        9      70       4            4JJC 080 010 090   8 X R0.5       19     110       8
                 4JJC 040 002 S04   4 X R0.1       10      60       6      New 4JJC 080 010 110     8 X R1         16     150       8
                 4JJC 040 002 S06   4 X R0.2        9      70       4      New 4JJC 080 010 150     8 X R1         19      60       8
                 4JJC 040 003 S04   4 X R0.2       10      60       6            4JJC 080 015 060   8 X R1         19      90       8
                 4JJC 040 003 S06   4 X R0.3        9      70       4            4JJC 080 015 090   8 X R1         19     110       8
                 4JJC 040 005 S04   4 X R0.3       10      60       6            4JJC 080 020 060   8 X R1.5       16     150       8
                 4JJC 040 005 S06   4 X R0.5        9      70       4            4JJC 080 020 090   8 X R1.5       19      60       8
                 4JJC 040 010 S04   4 X R0.5       10      60       6      New 4JJC 100 002 070     8 X R2         16      90       8
                 4JJC 040 010 S06   4 X R1          9      70       4      New 4JJC 100 002 100     8 X R2         19      60       8
                 4JJC 045 002 S06   4 X R1         10      60       6                               10 X R0.2      19      90      10
                                    4.5 X R0.2     11      70       6                               10 X R0.2      22      70      10
                                                           75                                                             100
